Type | Filling Machine |
---|---|
Condition | New |
Application | Food |
Packaging Type | Bag |
Packaging Material | Plastic |
Automatic Grade | Automatic |
Driven Type | Electric |
Power | 2.2KW/220V 50-60HZ |
Place of Origin | Tianjin, China (Mainland) |
Brand Name | Hondon |
Model Number | DXD-420 |
Packing speed | 5-60bag/min |
Bag-making size | (L)50-300mm,(W)60-200mm |
Bag-making type | Produce pillow bags,Vertical bag |
Max Filling range | 1300ml |
Max width of packing film | 420mm |
Film thickness | 0.04-0.08mm |
Air consumption | 200L/min,0.7*105.Pa |
Total power/voltage | 2.2KW/220V 50-60Hz |
Outside size | 1400*970*1800mm |
Gross Weight | 400kg |
Type | Packing Machine |
FOB Price: | Get Latest Price |
---|---|
Minimum Order Quantity: | 1 Set/Sets |
Port: | Tianjin |
Packaging Details: | Standard Export Wooden Case |
Delivery Time: | 7-15 working days |
Payment Terms: | L/C,D/A,D/P,T/T |
Supply Ability: | 3000 Set/Sets per Year |
Automatic Quantitative Weighing and Packaging Machine
I. Application of Automatic Packing Equipment
Automatic Packing Equipment is suitable for weighing material of grain, stick, slice , globose, irregular shape, such as candy , chocolate, jelly, melon seeds, peanuts, pistachios , almonds, walnuts, cashews, nuts, chips and such leisure foods , preserves( raisins, plum, etc), frozen food (frozen dumplings, etc), meatballs, fruit, vegetables, salads, cereals , shrimp, pet food, puffed food , hardware, plastic and so on .
II.Features:
1. The machine is controlled by the PLC computer control with touch screen that makes the operation very easy for the user.
2. The film is controlled by servo system, the packing is accurate and beautiful.
3. Equipped with perfect automatic alarm system.
4. This machine can accomplish the whole packing process such as feeding, filling, pouch making, data printing and so on.
5. A new multi language man machine interface allows you to operate the machine in the language of your choice via touch screen.
6. For guaranteeing stable long term operation of the machine, electrical equipment and pneumatic equipment are all made by famous manufactures of the world.
III.Main Technical Parameter:
ITEM |
Content |
Packing speed |
5-60bag/min |
Bag-making size |
(L)50-300mm(W)60-200mm |
Filling range |
150-1300ml |
Max packing film width |
420mm |
Total power/voltage |
2.2KW/220V 50-60Hz |
Outside size |
1400*970*1800mm |
Gross weight |
400kg |
Contact person:
Elena Liu
Your inquiry will be answered within 24hours.Pls feel free to contact me.We will do our best for you.
