Product Description

A collector and distributor is an assembly utilising a header pipe or a hub to which several filtering tubes are attached to enable collection or distribution of a gas or liquid, within a media. The purpose is to eliminate dead zones, wall effects or channelling in order to maximise efficiency.

DESIGN

Assembly - The purpose of the top or bottom, distributor and collector assembly is to collect or distribute a uniform flow within the media or for intermediate collection or distribution in mixed-bed processes. Attention must be applied to the need for backwashing or regeneration. Designs include a hub with spokes or parallel laterals.

Laterals - The smallest diameter is 21 mm and the finest slot is 30 microns. Each lateral consists of either a single wedgewire screen or screen jacket with an internal perforated pipe to control distribution and to add to mechanical strength where required.

Materials - stainless steel 304, 316, 904, hastelloy C276, Inconel 600 and 800 series, titanium T40, Duplex and Superduplex alloys etc.

Other Products

filter nozzle,nozzle strainer,filter strainer

header lateral,hub lateral,collector

resin traps

sieve bend screen,flat panel screen,V-shape profile wire screen

Company Profile

Name: Haixing wedgewires filter company

Main Products: filter nozzle,header lateral,hub lateral,resin traps,wedge wire screen,water well screen,steel casing pipe

Business Type: Manufacture

Total Employees: < 20

Address: number2589 west shengli road

Haixing wedgewires filter Company is known world-wide as a manufacturer of high quality Stainless wedge wire screens for the Water Intake and Waste Water, Fish Diversion and Hatchery, Petrochemical, Pulp and Paper,??Food and Beverage, and the Mining and Aggregate industries.??We also produce up-market, exotic, profile wire surfaces for Architectural uses; both functional and decorative.??Our customers number in the thousands in over 35 countries, and we list many Fortune 500 and international companies as long-term customers.
