high insulation class champagne color paint FJ9022AB,China Jasonfan price supplier

high insulation class champagne color paint FJ9022AB

FOB Price:Price can be negotiated

Production Capacity:80000 Piece/Pieces per Month

Payment Terms: US $2 - 3 / Piece

Update Time:2024-09-12

Contact Supplier

Product Description

Champagne color paint
industrial fan:Good cooling efficiency and low noise lever.

champagne color paint

Specification:

Motor Structure: Shaded Pole motor, with impedance protection
Blades: Made by injection mould with black plastic PBT+30% glass fiber + VO class of anti-flaming liquid.
Frame material: Die-casting Aluminum Alloy
Bearing Type: Maintain-free NMB bearing/sleeve bearing
Insulation Isolation Grade: B Protection Grade: IP 34
Dielectric Withstand Voltage: AC 1800V, at 0.5mA, 50/60Hz
Allowable Ambient Temperature: -20 to +70 Centigrade degree (ball bearing) (Under unconcretionary) -10 to +45 Centigrade degree (sleeve bearing)
Noise Lever: 29-35dB at normal operation
Life: 30,000 40,000hours
Connection way: UL1015 wire connection
Packing: 60pcs/carton
Unit weight: 260g

Specifications
Category	Axial fan
Type	FJ9022AB
Rated Voltage	115-230V
Frequency	50/60Hz
Current	0.06A-0.13A
Input Power	11W-12W
Speed	2250-2850RPM
Max Air Flow	29-37CFM
StaticPressure	57Pa-65Pa
Noise	32dB-34dB
Weight	0.26KG

Our Factory:

Production:

Quality Control:

Packing Details:

Type:	Axial Flow Fan	Electric Current Type:	AC	Mounting:	Free Standing
Blade Material:	Plastic	Place of Origin:	Zhejiang China (Mainland)	Brand Name:	Jasonfan
Model Number:	FJ9022AB	Voltage:	115-230V	Power:	50/60Hz
Air Volume:	29-37CFM	Speed:	2250-2850RPM	Certification:	CSA,CE,CCC,ROHS
After-sales Service Provided:	No overseas service provided	Motor Structure:	Shaded pole motor	Safety:	Impedance protected
Operation System:	Dual high precision ball bearings.(single sleeve bearing)	Dielectric Withstand Voltage:	AC 1800V at 0.5mA 50/60Hz	Allowable Ambient Temperature Range:	-25~+65 degree(ball bearing),-10~+45 degree(sleeve bearing)
Power Supply Connection:	UL3385-22 Lead wire,terminal connection	Insulation:	B Class	Protection Grade:	IP34
Unit weight:	0.26KG

Company Profile

Name: Wenzhou Jasonfan Manufacture Co., Ltd.

Main Products: Axial Fan,Air Filter,Cooling Fan,Centrifugal Fan,Finger Guard

Business Type: Manufacturer, Trading Company

Total Employees: 101 - 200 People

Established Year: 2006

Main Markets: Domestic Market, North America, Oceania, Southeast Asia, Western Europe

Address: NO.98 Xinhu Rd, Yuechen Town, Yueqing City, Zhejiang, China

We are specialized in developing and producing axial fans, centrifugal fans and air filters in different sizes with high quality in the cooling and ventilation fields. All of our products are reliable and they can work in harsh circumstance efficiently. They are featured in High airflow, Low noise and Durable life. Our company reposes on a simple Chinese city - Yueqing, which is famous for low-voltage electronics and precision industry around the world. Meanwhile, Jasonfan takes charge in offering the newest technique information and high-qualified design of products to all corporations. We took the spirit of this city and named our company Jasonfan.

Since our company came into existence, we have gained a good reputation in and out of Chinese market with outstanding quality and efficient service. Now clients from Australia, South Africa, Spain, Italy and other countries all designate to use our products. At the same time, we have set up a sales web-system covering almost all main cities in China, such as Beijing, Shanghai, and Chengdu.

Jasonfan has already obtained ISO9001:2000 national certification. Our products have got CSA, RoHS, CE, and CCC approvals. As our company develops quickly and steadily, up to March 2006, we had owned three factories, covering almost 4,000 square meters. At present, our monthly capability is more than 200,000 units of fans, 89% of which are produced by ourselves, including mold design, mold pouring, SMT disposal and all other assembling.

Devoted to the development of fans and insisting on high quality are the spirit and the principle of our company. We will try our best to satisfy the most rigorous inquiries of customers and make Jasonfan a worldwide welcomed brand. more
