automatic COCOA POWDER packing machine
1.carbon steel frame;
2.adjustable speed;
3.Constant temperature.
high quality automatic cocoa powder packing machine OMRON(Japan) Temperature contRoller
1.Machine photos 1:
automatic cocoa powder packing machine
2.Machine Photos 2:
automatic cocoa powder packing machine
3.Uses :
Suitable for large quantity shrink wrapping industries such as software, foodstuff, cosmetics, printing, pharmacy, flooring, ceramics, beverge and beer etc.
automatic cocoa powder packing machine
4.Samples:
automatic cocoa powder packing machine
5.Performance Characteristics :
1.The machine adopts imported touching screen,on which all settings and operation can be done. Meanwhile,various product data can be stored in advance,and operator only to select parameters from the computer while usage.
2.According to different collocations for the machine and different products, the max packing speed is up to 80pcs/min.
3.Constant temperature heat sealing and cutting system is suitable for PE. POF etc, industrial standard shrink films, the seal is firm and nice, especially applicable for POF film, adjust the conveyor with the head wheel for packing products of different size. The reliability is higher and easier to operate it .
4.The front feed in systems speed is adjustable, combines a worktable at the end of the tunnel, makes whole machine highly automatic, it runs automatically without an operator comes true.
5.BM-500L Hi-speed hot air circulating shrink tunnel adopts roller type conveyor, the rollers are covered by silicone gel pipe, they roll automatically, also the conveyor can use Teflon mesh belt or S.S. mesh belt instead of rollers. When shrink PE film, need not the rollers roll, easy to convert it by the handle at the end of the tunnel.
6.The temperature inside the tunnel is even, suitable for shrink PE.PVC.POF films.
7.The inner container forms hot air circulation inside tunnel,the volume of hot air can be controlled by the air doors according to the packing requirements for different products.
automatic cocoa powder packing machine
6.Spare parts1:
automatic cocoa powder packing machine
7.Spare parts 2:
automatic cocoa powder packing machine
8.Main Technical Parameters:
| Model | BTH-450 | BM-500L |
| Max Packing Size | L (W+H) ≤ 400mm (H) ≤ 130mm | (L)1500×(W)450×(H)250mm |
| Max sealing Size | (W+H)≤450mm | (L)1500×(W)500×(H)300mm |
| Packing Speed | 30~80 packs/min | 30~80 packs/min |
| Electric Supply & Power | 380V/50Hz 3kw | 380V/50Hz 16kw |
| Max Current | 10A | 32A |
| Air Pressure | 5.5kg/cm3 | / |
| Weight | 800kg | 650kg |
| Overall Dimensions | (L)2050×(W)1500×(H)1300mm | (L)1800×(W)1100×(H)1300mm |
automatic cocoa powder packing machine
9.Spare parts 3:
co automatic cocoa powder packing machine
10.Component List:
| No. |
Item |
Brand |
Qty |
| 1 |
Cutting knife servo motor |
PANASONIC (Japan) |
1 |
| 2 |
product feeding motor |
TPG ( Japan ) |
1 |
| 3 |
discharged motor |
TPG ( Japan ) |
1 |
| 4 |
film unwind motor |
TPG ( Japan ) |
1 |
| 5 |
waste film recycling motor |
TPG ( Japan ) |
1 |
| 6 |
PLC |
OMRON (Japan) |
1 |
| 7 |
Touch screen |
MCGS |
1 |
| 8 |
servo motor driver |
PANASONIC (Japan) |
1 |
| 9 |
product feeding inverter |
OMRON (Japan) |
1 |
| 10 |
discharged inverter |
OMRON (Japan) |
1 |
| 11 |
Film unwind inverter |
OMRON (Japan) |
1 |
| 12 |
waste film recycling inverter |
OMRON (Japan) |
1 |
| 13 |
Breaker |
SCHNEIDER ( France ) |
10 |
| 14 |
Temperature controller |
OMRON (Japan) |
2 |
| 15 |
Contactor |
SCHNEIDER ( France ) |
1 |
c automatic cocoa powder packing machine
11. Workshop 1:
automatic cocoa powder packing machine
12.Workshop 2:
automatic cocoa powder packing machine
13.Equipment:
automatic cocoa powder packing machine
14.exhibition:
automatic cocoa powder packing machine
15.Visit figure:
automatic cocoa powder packing machine
16.Certificates:
automatic cocoa powder packing machine
17.Shipment Details:
automatic cocoa powder packing machine
18.We Promise:
12 Months guarantee,during this period we will offer free replacement after confirming that it is our quality problems.
If you want to know more information about our products welcome to contact us in any time, And welcome to our company!!!
| Type: |
Wrapping Machine
|
Condition: |
New
|
Application: |
Food,Beverage,Commodity,Medical,Chemical,Machinery & Hardware
|
| Packaging Type: |
Cartons
|
Packaging Material: |
Wood
|
Automatic Grade: |
Automatic
|
| Driven Type: |
Electric
|
Voltage: |
380v
|
Power: |
3kw
|
| Place of Origin: |
Shanghai China (Mainland)
|
Brand Name: |
QCPACK
|
Model Number: |
BTH-450+BM-500L
|
| Dimension(L*W*H): |
2050*1500*1300mm+1800*1100*1300mm
|
Weight: |
800kg+650kg
|
Certification: |
CE
|
| After-sales Service Provided: |
Engineers available to service machinery overseas
|
Name: |
automatic cocoa powder packing machine
|
Warranty: |
12 months
|
| Cutting knife servo motor: |
PANASONIC
|
product feeding motor: |
TPG
|
PLC: |
OMRON
|
| Touch screen: |
MCGS
|
Temperature controller: |
OMRON
|
Horizontal sensor: |
BANNER
|
| Sealing knife: |
DAIDO
|
Conveyor: |
SIEGLING
|
