High Quality cocoa powder mixer

FOB Price:Price can be negotiated

Production Capacity:200 Set/Sets per Month

Payment Terms: US $1,000 - 10,000 / Set

Update Time:2014-09-20

Contact Supplier

Product Description

COCOA POWDER Mixer
1.High Mixing Effect
2.Rapid Mixing Time
3.CE
4.SIEMENS Motor,Sumitomo Bearing

Introduction of cocoa powder mixer

Ribbon mixer consists of U shape shell ,double ribbons and drive unit.

The exterior ribbon transfers raw material from the two ends to center while the interior ribbon moves

the material in opposite in the form of counter-current movement.

Ribbons can be changed into paddles,and chopper is optional for different materials.

The top cover can be concave for pressure application ,or full open way to allow for easy cleaning.

The advantages of cocoa powder mixer

1.High Mixing Effect

2.Rapid Mixing Time

3.Large Loading Ratio

4.Wide Application

5.Wear-Resistence and Low Maintenence

Model Project	Total Volume (M³)	Loads coefficient	Electrical machiney power (KW)	Size(mm)× Max-diameter ×High	Equipment weight (kg)
JHRB-0.15	0.15	0.4-0.8	3	1190×740×770	330
JHRB-0.3	0.3	0.4-0.8	4	2030×630×980	720
JHRB-0.5	0.5	0.4-0.8	7.5	2320×730×1130	980
JHRB-1	1	0.4-0.8	11	2800×920×1320	1700
JHRB-1.5	1.5	0.4-0.8	11	3180×1020×1550	1800
JHRB-2	2	0.4-0.8	15	3310×1120×1640	2100
JHRB-3	3	0.4-0.8	18.5	3750×1290×1820	3000
JHRB-4	4	0.4-0.8	22	4220×1400×1990	3980
JHRB-5	5	0.4-0.8	22	4220×1500×2100	4620
JHRB-6	6	0.4-0.8	30	4700×1610×2260	6180
JHRB-8	8	0.4-0.8	37	4420×2150×2470	8200
JHRB-10	10	0.4-0.8	45	5520×2960×2720	8920
JHRB-12	12	0.4-0.8	45	5720×3010×2840	9520
JHRB-15	15	0.4-0.8	55	5840×3540×2940	9950

Internal Structure

Manufacturing Process

Applications

Packaging & Shipping

Our Services

An experienced and well mannered sales and marketing team is committed to bringing you 100% customer satisfaction. In order to succeed in the rapidly changing podwer mixer market, our company has instituted a development policy that emphasizes "Serving the customer, improving products, providing best service,sureness and steadiness, devotion and dedication".Please feel free to contact us at any time.

Company Information

Zhengzhou Jin Tai Metal Materials Co., Ltd. cleaves to the spirits of ” Creat in China ” in the field, devoting research to innovating in order to improve the efficiency and save more energy . At present we have the independent intellectual rights and national patent technology of our products .

Certificates

Exihibition

FAQ

1.Some remarkable questions in the process of use.

Because the Dry Powder Mixer Machine is electrical equipment, so the operator should pay attention to electricity safety.

2.How to maintain dry mixer?
1.)Ensure that the Dry Powder Mixer Machine and the surrounding environment clean.
2.)Regular checks of the various systems, such as tainted ash, gas leakage, oil spills and leakage phenomenon timely processing.

Condition:	New	Mixer Type:	Ribbon	Product Type:	powder
Application:	Powder	Additional Capabilities:	cooling	Place of Origin:	Henan China (Mainland)
Brand Name:	JINHE	Model Number:	JHRB5000L	Max. Loading Capacity:	2500L
Voltage:	110V-415V	Power(W):	22KW	Dimension(LWH):	422015002100mm
Certification:	CE,ROHS	Warranty:	one year	After-sales Service Provided:	Engineers available to service machinery overseas
Model:	JHRB5000L	Barrel Volume(L):	5000L	Biggest Capacity(KG):	5000
Motor Powder(kw):	22	weight(KG):	4620	Certificate:	CE,ROHS
