HLD Hopper Mixer Machine,China YIBU price supplier

HLD Hopper Mixer Machine

FOB Price:Price can be negotiated

Production Capacity:1 Set/Sets per Month

Payment Terms: US $8,333 - 9,600 / Set

Update Time:2021-09-23

Contact Supplier

Product Description

Lass="description"> HLD Hopper Mixer Machine for solid medicine powder in pharmaceutical industry worldwide.

HLD Series Hopper Mixing Machine(Bin Blender)

HLD Series Hopper Mixing Machine(Bin Blender)

Applications
It's widely used as the mixing machine for solid medicine powder in pharmaceutical industry worldwide. The mixing uniformity is high, the material vessel is movable, these are very convenient for material loading, mixing, discharging and cleaning. It's easy to integrate with the upstream and downstream process, the problem of cross pollution and fly-dust caused by multi-material-transferring are solved. Various of material vessel might be equipped with this machine, so to meet the mixing requirement of large batch capacity, and multi-varities.

Principle
Through years of studying, comparing and absorbing both domestic and foreign machines, we develop our own design of HLD series hopper lifting machine.
The main structure feature of the mixer is: The mixing body (material vessel) and the rotating axis form a angle of 30°. When the material is rotating, the material also makes tangent movement along the wall of the vessel. The function of these to movements makes all points of material moves in complicated ways, changes their positions all the time, so to have very high mixing efficiency.

Features
1. The structure is reasonable, adopt double hoisting devices, motor rotation, flexible coupler. The performance is stable, the upkeep and maintenance and simpler, and there's no problem of leakage.
2. Adopt programmed control system, technical parameters setting system, machine stops system for safety, automatic accurate positioning system, operation, and automatic record printing system, that fully meet processing equipments of pharmaceutical companies. Fully automatic production is realized, and the operation is very simple.
3. To ensure the quality of the machine, we adopt high quality out purchased parts for this machine.
4. Equipped with fine manufactured hopper that fully meet the requirements of GMP, no residues of discharge, and it's easy for cleaning or washing.
5. We supply series product for material conveying. It forms advanced process together with the hopper mixing machine.
Remarks: If customer has any special requirements, please special order.

Technical parameters

spec parameter	HLD-800	HLD1000	HLD1200	HLD-1500	HLD2000
A	2900	3100	3175	3350	3770
B	2550	2600	2700	2850	3300
C	1850	1900	1950	2100	2650
D	1600	1650	1700	1800	2050
E	700	700	700	700	700
F	1000	1200	1200	1200	1200
G	1500	1500	1500	1600	1600
L	3050	3300	3400	3550	3550
K	2000	2150	2150	2200	2200
power kw	7	7	7	9.7	9.7
net load	400	500	600	750	1000
weight	2500	2800	3000	3500	4000

Place of Origin:	China	Brand Name:	YIBU	Model Number:	HLD(-800-2000)
Certification:	ISO14001, ISO9001	Processing:	Mixer	Processing Types:	solid medicine
