Horizontal Cocoa Powder Seperation Machinefor with 160mesh and 100~500 kg per hour,China Zhenying price supplier

Horizontal Cocoa Powder Seperation Machinefor with 160mesh and 100~500 kg per hour

FOB Price:Price can be negotiated

Production Capacity:200 Set/Sets per Month

Payment Terms: US $1,000 - 100,000 / Set

Update Time:2014-09-20

Contact Supplier

Product Description

Horizontal Airflow Screen
1.CE & ISO9001certified.
2.Anti-splash guard.
3.no blockage.
4.5~160 mesh cocoa powder

Description

The cylinder screen mesh of this device is placed inside the machine. The materials enter the net tube with airflow mixed and atomized after passing the screw conveying system; some of the materials are sprayed through the net and discharged from the fine stuff portal by the centrifugal force and cyclone propelling power, which are caused by the rotor vane inside the net tube. Other materials which cannot cross the net, are discharged from the rough stuff portal along the net tube wall.

Application

The machine is available in the industries such as metallurgy, mining, pharmacy, food, chemical engineering, metal powder and nonmetal powder etc.

Feature

1 The whole machine is in a small size and light so that it is stable in operation, free from vibration and noise, and with its good sealed structure, it is free from dust and performs in high efficiency.
2 The shell of machine is in a new design which makes it easy to install and convenient to control.
3 The machine can operate either in a single unit or multiple units, and it is safe and reliable for a long time operation.
4 The screen-mesh can be cleaned automatically by cyclone.
5 The machine has the function of re-crashing the agglomeration materials.
6 The new type roller bearing can prolong the service life.
7 The machine can work with the pneumatic conveying systems, and materials can be directly sent into the wind path to save resources.
8 New design: The airflow protection system can transfer the purified air to the two ends of the device, which will reduce the temperature created in the operation of the device.
9 It will form the air-isolated layer to avoid the powder entering the bearing so as to prolong the service life of the bearing effectively, reduce the maintenance frequency, and increase work efficiency.
10 The machine can be specially designed to meet special requirements.

Technical Parameter

Model	A	B	C	D	E	F	G	H	I	J
ZYQW18-65	1430	460	420	1005	135	230	250	330	340	210
ZYQW25-85	1845	655	766	1240	320	285	300	350	380	290
ZYQW50-130	2230	870	790	1775	280	515	150	660	400	485

Some parts

Machine in our factory

Machine in our clients' factrory

Thanks for your attentions,any requirement,please eamil me.

i am service of you at any time!!!

Place of Origin:	Henan China (Mainland)	Brand Name:	Zhenying	Model Number:	ZYQW
Type:	Separation	Feeding Design:	Conveyor Design"> Screw Conveyor Design	Material:	SUS 304 or 316L
Screen mesh:	5~250mesh	Capacity:	50~500kg/h	Color:	Gray ( make blast sanding on the surface)
Voltage:	380V or optional	Rpm:	1440	Cleaning system:	Air flow cleaning
Free Spare parts:	Sealing ring and some tool	Application:	Food industry
