Ice cream Batch Freezer
ice cream machine has frequency control device, easy-to-read electronic module, Batch freezers come in different sizes from 7L up to 35L and produce a batch in about 8-12 minutes depending on the way the machine is cooled. The refrigeration compressors come from France, Italy or the USA. Most other parts are European.
Gelato hard ice cream freezer has these features:
The new model Gelato machine has a new dasher and an industrial quality frequency control device. The dasher improves overrun. Frequency control makes the machine extremely quiet, improves temperature control and will add years to the operating life of the dasher motor. Shows the progress of the batch and has a fault finding mode.
Frankly, these are the first real improvements in batch freezer design . Batch freezers come in and produce a batch in about 8-12 minutes depending on the way the machine is cooled.
The technical data of the GELATO BATCH FREEZER.
| Model |
VITA 10 30 |
VITA 15 45 |
VITA 20 60 |
VITA 60 120 |
| Cylinder/liters |
7 |
10 |
15 |
35 |
| Mix added/batch(KG) |
1.5-5.0 |
2.5-7.5 |
3-10.5 |
8-24.5 |
| Mix added/hour(KG) |
10-30 |
15-45 |
20-60 |
60-120 |
| Control system |
electronic, computer; Hardness control system, after cooling cycle |
| Agitator design |
replaceable blades with self regulating leaf spring |
| Batch time/min |
8-10 |
8-10 |
9-12 |
10-15 |
| Production capacity/hour |
12-42 liters |
21-63 liters |
28-90 liters |
72-140 liters |
| Electricity Specification/volt |
230/400 |
230/400 |
230/400 |
230/400 |
| Electricity Specification/Hz |
50 or 60 |
50 or 60 |
50 or 60 |
50 or 60 |
| Electricity Specification/Ph |
1 or 3 |
3 |
3 |
3 |
| Refrigerant type |
R404A |
R404A |
R404A |
R404A |
| condenser |
water or air |
water or air |
water or air |
water or air |
| Rated power |
5.3kw |
6.1w |
7.8w |
10.1kw |
| Frame type |
Floor |
| Construction |
powder coated against corrosion |
| Outer Panel Material |
stainless steel AISI 304 |
| Net weight |
452 lbs/205 kg |
505 lbs/229 kg |
633 lbs/287 kg |
774 lbs/351 kg |
| Gross weight |
507 lbs/ 230 kg |
562 lbs/255 kg |
683 lbs/310 kg |
871 lbs/395 kg |
| Size Wx D x H(with wheels) |
500*650*1400mm |
500*650*1400mm |
500*650*1400mm |
600*800*1450mm |
| 20*26*55 inch |
20*26*55 inch |
20*26*55 inch |
24*32*57 inch |
| Packing size W x D x H |
600*750*1550mm |
600*750*1550mm |
600*750*1550mm |
700*900*1600mm |
| 24*30*61 inch |
24*30*61 inch |
24*30*61 inch |
28*35*63 inch |
Note:
Other voltages and cycles available at additional cost. Air-cooled version available at additional cost. Hourly production may vary according to the mix used. The quantity of gelato and hourly prodution vary according to the raw mateirals. The Max values refer to the classic spreadable Italian ice cream gelato.
