ice cream Egg roll wafer processing line,China price supplier

Egg roll machine(wafer stick line)

  to make two colors wafer stick (inside filled with cream/ chocolate, etc).

Capacity: normal shape 50kg/h(about 100 pieces/min), count on the basis of φ10.5 inject pipe, 25% cream inside, roll’ length is 100mm

Gas consumption: LPG<=4.5kg/hr, Natural Gas <= 10CBM/hr

Gas supply pressure: 4kpa

Power: 7.5Kw

Exterior Size: L 3.2m/W 1.8m/ H 2.3m

Weight: 5200kg

Complete wafer stick machine included:

wafer stick main machine

Cooling Conveyor 4m

15kgs batter mixer

Cream mixer

Dough strips with a high sugar content (40-70%) are poured onto a rotating heated baking drum or a baking ring. After baking, stripping knives release the flexible dough bands, which are then wound around mandrels to form wafer sticks. cut to the required length and fed to a collecting conveyor. The thickness and the width of the strip of batter can be adjusted.

The sticks are cut to the desired length and move via a chute or a stick Elevator to a collecting belt.
Additional devices such as pressing belts, pillow shape cutter, cream filling units or the double pouring device allow numerous value-added variations of the simple standard wafer stick.

Possible Products:
1, Hollow wafer stick (one / two colors)
2, Wafer stick with cream filling
3, Pillow shape wafer stick
4, Pressed wafer stick
5, Chocolate enrobing wafer stick

Wafer stick main machine
included:

1, Baking oven
2, Batter and cream supply machine
3, Cooling conveyor
Baking

Wafer stick main machine specification

1, Hollow wafer stick (one / two colors) 2, Wafer stick with cream filling

Capacity: normal shape 50kg/h(about 100 pieces/min), count on the basis of φ10.5inject pipe, 25% cream inside, roll’s length is100mm

Total power: 6.6kw

Total weight: 4610kg
Workshop dimension: 10000*7000*3500 mm(L*W*H)

Pillow shape cutter specification
Cutting Machine for pillow shape wafer stick

Product: two colors pillow shape wafer stick

Capacity:
50kg/h (about 300 pieces/min), count on the basis of φ10.5 inject pipe, 25% cream inside, roll’s length: 33mm

Press belt system specification
Press drive for pressed wafer stick.

Added a press belt to the end of the cooling conveyor used to press the hollow wafer stick (without cream filling) to pressed wafer stick.

Pressed wafer stick
Capacity: normal shape (about 160 pieces/min), count on the basis on lengh:60mm, width:18mm, thick:5-6mm.

Egg roll (wafer stick)packing
