CFD Model Ice Cream Packing Machine / Wrapping Machine
Calippo ice cream or sobert filling machine specail for calippo tube auto filling & sealing !
Callipo Packing Machine
Callipo Filling and sealing machine(Packaging machine,Packaging machinery)
All new design.
A packaging machine specially designed for ice-cream filling and sealing.
A highly automated machine. The operation cycle, from filling, sealing to product outfeed are fully automatically performed.
Easy to operate , 2 workers can be ok for machine
Less maintenance.
It's a necessity in mass production line.
Applicable Products:
ice-cream , sobert, honey, jelly, jam...
Outstanding Features and Construction:
l Feeding cup by hand
l Two-step auto ng device permits adjustment of filling quantity.
l Two-step auto sealing make sure the film firm, and have a high percent of finished product
l Feeding materials from charging bucket automatically.
l Single Pre-cut Aliuminum Lid Auto application
rding to the buyers demands, the imported components and equipped with PLC system can be added to the machine, and the date-printing device are also added
l According to the buyers demands, adding some materials , such as fruit flesh , calcium grain, solid particle to the cups.
Note : we can add or delete some devices according to your requirements!
Technical Specification
Model |
CFD-5 |
Packaging Speed: |
4,800- 6,000 pcs / hour |
Filling Volume: |
50--15ml |
|
|
Power: |
3-phase 4-line socket(380V50HZ) |
Electric Machinery Power: |
0.75kw |
Heat Up Power: |
4kw |
Air Pressure: |
0.5Mpa-0.7Mpa |
Max.Air Consumption: |
0.45m 3 /min |
Timing Mode |
Electric Frequency Inverter |
Machine Dimension(L*W*H) |
4000*800*1700mm |
Package Dimension(L*W*H) |
4150*950*1850mm |
G.W. |
1350kg |
N.W. |
1200kg |
Note: All specifications, design and characteristics shown in the catalogue are subject to change without prior notice. |
Founded in 1998, XinChuang Packing & Food Machinery Company is a company that integrates research and development, manufacture, sales and consultation. Our products are exported to the USA, Japan, Australia, Indonesia, India, Malaysia, New Zealand, France, Russia, Kazakhstan, Vietnam and some African countries. Moreover, we have won local and national recognition for our high quality products and excellent services.
