juice milk uht tube sterilizer,China Beyond price supplier

juice milk uht tube sterilizer
FOB Price:Price can be negotiated
Production Capacity:100 Set/Sets per Year
Payment Terms: US $100,000 - 1,000,000 / Set
Update Time:2023-11-01
Product Description

tubular sterilizer with Modular system for complete flexibility, fully automatic control by PLC and touch screen



Description for  tube sterilizer :

Field of application: Juice Beverage and other liquid food industries. The tubular heat exchanger unit is designed for sterilizing and cooling of milk and juice as well as products containing fibers and particles. The sterilization temperature is typically 135~ 140C for 4 seconds holding. .



Standard design: The unit is pre-assembled and tested before it leaves the factory. The installation on site only require connection to external service such as product inlet and outlet, water, steam, air and electricity.

The unit comprises:
- Frame
- Set of tubular heat exchangers with:

Regenerating section
    Sterilization section
    Hot water section
    Cooling section
- Balance Tank
- Product pump
- Holding tube
- Hot water pump
- Control panel with:
    PLC controller
    Color Human Machine Interface
    Alarm for high and low temperature
    Alarm for high temperature and low flow in hot water section
    Start/stop buttons for pumps
    Indicator for and control of pasteurizing temperature
- Set of internal pipes, valves and fittings

The unit is designed for CIP via recirculation over the balance tank and dosing of chemicals automatically.



Parameters
Temperature profile: 5
°C →65 °C →95 °C / 30S→140 °C / 4S→25 °C
Ice water 1:1 (≤2
°C Spare)        Cooling water 1:1(30 °C Spare)

modle

LG-UHT-1

LG-UHT-2

LG-UHT-3

LG-UHT-4

LG-UHT-5

Production capacity ( L/H )

1000

2000

3000

4000

5000

Inlet temperature

5 °C

5 °C

5 °C

5 °C

5 °C

Holding time(s)

4-15

4-15

4-15

4-15

4-15

Sterilize temperature

105 ~ 143 °C

105 ~ 143 °C

105 ~ 143 °C

105 ~ 143 °C

105 ~ 143 °C

Product outlet temperature

20

20

20

20

20

Icewater inlet temperature

≤2 °C

≤2 °C

≤2 °C

≤2 °C

≤2 °C

Steam pressure

0.5MPa

0.5MPa

0.5MPa

0.5 MPa

0.5 MPa

Steam consumption

~ 150Kg/h

~ 210Kg/h

~ 280Kg/H

~ 350Kg/h

~ 420Kg/h

Compressed air pressure

0.6MPa

0.6MPa

0.6MPa

0.6MPa

0.6MPa

Compressed air consumption

50L/H

50L/H

60L/H

60L/H

70 L/H

External dimension

( homogenizer excluded )

3500×2000×2500

3500×2000×2500

4500×2500×2200

5000×2000×2200

5000×2000×2200

Total weight of machine

1700kg

2000Kg

2200 Kg

2500Kg

2800kg



       juice milk uht tube sterilizer



juice milk uht tube sterilizer



juice milk uht tube sterilizer















Condition:
New
Place of Origin:
Shanghai China (Mainland)
Brand Name:
Beyond
Model Number:
5T/H
Type:
pasteurization
Voltage:
380V
Power(W):
8kw
Weight:
1250kg
Dimension(L*W*H):
2250*2000*2200
Certification:
ISO 9001
Construction material:
SUS316L/SUS304
ontrol type:
automatic
Certificate:
ISO9001:2008/HACCP/GMP
Energy consumption:
Low consumption
Effeciency:
high effeciency
