KD-350 Automatic Chocolate Bars Packing Machine,China Huayuan price supplier

KD-350 Automatic Chocolate Bars Packing Machine

FOB Price:Price can be negotiated

Production Capacity:300 Set/Sets per Month

Update Time:2014-09-28

Contact Supplier

Product Description

1.Speed:180bags/min
2.It is comply with GMP standard.
3.CE certification
4.ISO 9001:2008

Featrues
Compact structure, stable function and simple operation.
Double frequency converter controller,length of package will cut immediately once setting, adjustment needless, saving time and film.
It adopts imported electric appliance, touch manmachine interface, convenient parameter setting.
Self-cheching function, trouble can be read easily. High sensor photoelectric color chart tracking, make the cutting position more correctly.
Dependant temperature PID controlling suitable for various materials of packagingmenbrane.Position stop function, no adhesive and no waste of membrane.
Clean rotation system, more reliableoperation and more convenient maintenance.
All the controlling operates by the software,convenience for function ad-justment and technical up grading.
Main Technical Data

Finished package size(mm)	Length65330mm Width30150mmHeight5*40mm
Vertical and cross sealing strength (Nuton/mm)	15N/mm²
Packaging speed(bag/minute)	40~220Bags/min
Packaging film width(mm)	90~350mm
Power specification	220V 50/60Hz 2.7KW
Machine weight	550KG
Overall size (length x width x height)	3780 x 640 x1560mm

Type:	Other,General	Condition:	New	Application:	Food,Apparel
Packaging Type:	Cartons,Bags	Packaging Material:	Plastic	Automatic Grade:	Automatic
Driven Type:	Electric	Voltage:	220V	Power:	2.7KW
Place of Origin:	Zhejiang China (Mainland)	Brand Name:	Huayuan	Model Number:	KD-350B
Weight:	550KG	Dimension(LWH):	3780mm640mm1560mm	Certification:	CE
After-sales Service Provided:	Overseas service center available	Usage:	Outer	Materials:	Stainless Steel

Company Profile

Name: Ruian Huayuan Packing Machinery Factory

Main Products: Food Packing Machine,Daily Necessities Packing Machine

Business Type: Manufacturer

Total Employees: 11 - 50 People

Established Year: 2004

Main Markets: Domestic Market, Mid East, South Asia

Address: Swiss Lake Road,Dong feng road,Ruian city,Zhejiang province,China

Ruian HuaYuan packing machinery factory set up in 1987,is a professional company to manufacture varies of packaging machines.It creatively integrates design ,manufacturing,sale and after-sale service,it also has consummated management system and strong technical team.
At present,our main products are:pillow-type packing machine,blister packing machine,vertical packaging machine,capsule filling machine,cartoning machine etc.Our packing machinery products hold a lead in the fields in China,and are also exported to the United States,Russia,Southeast Asia,Europe,And other regions.
At the same time,our packaging machinery had passed the certification of ISO9001:2008.All the machinery products comply with GMP standard.
We wish domestic and international customers cooperate with us for a long time,and you are welcomed to our company visit,guidance or call consultation. more
