Product Description

1. Introduction

JC-340 automatic blow molding and plastic sucking lids forming machine are developed by our research and development personnel according to the demand of packing market. In combination with the advantages of aluminum-plastic blister packing machine and plastic sucking forming machine, this machine is a new type product developed in light of pharmaceutical standard GMP and food standard QS. This machine adopts a fully automatic flow covering blow molding or plastic suction molding, punching and diet cutting as the special properties of products required by the users. It is with advanced technology, safe and simple operation, which will avoid the consumption of labor on the manual punching and contamination from the touch with the employee. Therefore, the quality requirement is secured during the production. Aligned heating is employed by the equipment, and it enjoys low power consumption, small covering of land.

A: By blister forming methods

a: Pressure blow molding machines (ordinary type)

B: Molding + pressure type mechanical models (special type)

B: By Electrical configuration

a: PLC Push-button control

b: PLC+Touch Panel Control

Note: The packaging machine specific models to determine from the contract.

2. Application

It is applicable to the plastic ware such as PVC, PET, PS medicine trays, and cup lids thermoforming boxes.

3. Operation Process

1\ PVC stock supporting

2\ PVC Preheating

3\ Thermal Forming

4\ Punching holes

5\ Manipulator Traction, Plate length control

6\Plate Shearing

7\ Get waste material and finished products

4. Performance features

1\ Speed reducer, main-rotating connection, main shaft are on line (to decrease driving error) for mechanical transmission.

2\ Sensor controls are adopted in pneumatic system .PLC control makes the whole machine run smoothly, keeps synchronous stability during the products are to be packed in multi-labor, long- distance .

3\ Main motor non-stop speed regulating, the travel adjustable at will, simple and convenient to change the mold, manipulator traction, stable running.

4\ Positive pressure formation in the equipment.

5\ Deep forming

Note: According to the customer’s requirement, equipped with negative pressure forming.

5. Advantages

1\ The machine is made of stainless steel.

2\ It's set with man-machine touch screen, equipment sensor. You can change different languages, know how many you've done, and so on.

3\ It's with beautiful shape, small area coverage, multi-functions and for longer use.

It operates rather smoothly. One person is enough to operate this machine, and you can know how many lids

having been produced and you can also set the quantity you want to produce through man-machine touch screen.

4\ Simple structure enables you understand at once. We introduced advanced technologies from abroad and developed from complication to simpleness with high intensity.

5\ It's easy to operate. One person is enough, which is convenient for modern administration and saves the manpower and improves efficiency.

6\ It's clean with full waste recycling system, thus reduce the usage of pvs material.

6. Main technical parameters

Punch Frequency	15-40pcs/min	Total Power	4.5kw
Mould cooling	Tap water or recycle water 60 L/H	PVC hard pieces	0.15-0.5×350mm
Max. Forming area	330×160mm	Over all dimension	1900×790×1700mm
Stroke	65-165mm	Max. Forming depth	47mm
Compressed air	0.6-0.8(mpa)	Weight	950kg
