Product Description

The Processing Line can produce:
(1) flat-type lollipop candies
(2)ball-type lollipop
(3two-color striped lollipops

The processing line is an advanced and continuous plant for making different sizes of flat-type lollipop candies(stick-add by manual for flat pops) ,also can make the two-color striped lollipops, and ball-type lollipop (stick –adding can be done automatically) and hard candies. It is an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied.

COMMODITY:

GDL150/300/450L deposited hard candy & lollipop producing line

FEATURES:

1) PLC /computer process control available;

2) An LED touch panel for easy operating;

3) The production capacity from 150 kgs/h to 450kgs/h;

4) The main body is made of hygienic Stainless Steel

5) Optional (mass) flowing controlled by Frequency inverters ;

6) In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid;

7) Dosing pumps for the automatic injection of colors, flavors and acids;

8) Use AUTOMATIC STEAM CONTROL SYSTEM instead of manual steam valve which controls a stable steam supply to the microfilm cooker;

“two-color striped” lollipop, candies can be made.

TECHNICAL SPECIFICATIONS:

Model	GDL150	GDL300	GDL450	GDL600
Production capacity kg/h (based on 6gm candy)	120	250	350	400
Max. of the product g	10	10	10	10
Speed of stroke n/min	20~25	20~25	20~25	20~25
Steam consumption kg/h Steam pressure Mpa	250 0.2~0.6	300 0.2~0.6	400 0.2~0.6	500 0.2~0.6
Electric power needed	18kw/380V	27kw/380V	34kw/380V	42kw/380V
Compressed air consumption Compressed air pressure	0.2m ³ /min 0.4-0.6Mpa	0.25m ³ /min 0.4-0.6 Mpa	0.3m ³ /min 0.4-0.6Mpa	0.4m3/min 0.4~0.6Mpa
Conditions needed for the cooling system: 1.Room temperature(°C) 2.Humidity (%)	20~25 55	20~25 55	20~25 55	20~25 55
Gross weight Kgs	4500	5500	6500	8500

FLOW DIAGRAM:

Sugar dissolving→ syrup storage→ micro-film cooking→ depositing → stick -adding→ cooling→packaging

MAIN EQUIPMENT LIST:

The whole line is comprised of following equipment:

COMMODITY: LOLLIPOP DEPOSITING PROCESSING LINE

MODEL: GDL300

NO.	EQUIPMENT	SPECI.
1	FIXED COOKER with stirring device	300 L
2	GEAR PUMP	1
3	STORAGE TANK	200L
4	Connecting pipes and valves (SS)
5	VACUUM MICROFILM COOKING UNIT with auto steam control system 5-1.MAIN MICROFILM COOKER (1) 5-2.PRE-HEATER(1) 5-3.VACUUM PUMP(1) 5-4.FEEDING PUMP with frequency inverter(1) 5-5.DISCHARGINGPUMPwith frequency inverter(1) 5-6.CONNECTING PIPES & VALVES(1set) 5-7.PLC CONTROLER(1)-MITSHUBISHI	300KGS/H
6	DEPOSITING CANDY UNIT: 6-1.DEPOSITING MACHINE(1) 6-2 DOSING PUMPS(4) 6-2.1 automatic stick insertion system(1) (a patent by YINRICH®) 6-3.INDUSTRIAL COOLING SYSTEM(1set) 6-3.FLAVOUR MIXER(2) 6-4.CONNECTING PIPES(1set) 6-5.PLC CONNECTING(1)	300KGS/H
7	MOULDS for lollipop	500PCS
8	Mould for hard candy	500pcs

Place of Origin:	China (Mainland)	Brand Name:	Yinrich	Model Number:	GDL150/300/450/600
Type:	Other	Certificate 1:	CE	Certificate 2:	CQC
Certificate 3:	ISO9001:2000
