1 lollipop packing line
2 Chinese and English display control system
3 Advanced PLC touch screen
lollipop packing line
Features
1 Dual frequency conversion control, Bag length can be set cut in one step, saving time and film.
2 Reasonable construct, stable working performance, PLC computer control, easy operation
3 Self diagnosis failure function, clear failure display.
4 High sensitivity optical electric color mark tracking and digital input cut position which makes the sealing and cutting more accurate.
5 Stopping the machine in selected position, no sticking to the knife and no waste packing film.
Applications
Suitable for solid type product pillow packaging such as biscuits, Bread egg roll, instant noodles, moon cakes, hardware, industrial parts, paper boxes, plates, etc.
Technical Parameters
| Model |
GQ-350 |
GQ-450 |
| Film width |
Max.350mm |
Max.450mm |
| Film thickness |
0.03-0.07mm |
0.03-0.07mm |
| Bag making length |
65-190 or 120-280mm |
90-220 or 150-330mm |
| Bag making width |
30-110mm |
50-160mm |
| Production height |
Max.40mm |
Max.80mm |
| Packaging speed |
40-230bag/min |
20-200bag/min |
| Packaging material |
OPP , PE , PVC, OPP/CPP, KOP/CPP, ALU-FOIL |
OPP , PE , PVC, OPP/CPP, KOP/CPP, ALU-FOIL |
| Power specification |
3.4Kw/220v, 50/60Hz |
4.2Kw/220v, 50/60Hz |
| Outside dimension |
4020*770*1450mm |
4380*870*1500mm |
| Gross weight |
600kg |
800kg |
Test-run a pillow automatic packaging equipment
Samples
Company Pictures
We will be glad to establish various cooperation with domestic and aboard enterprises to achieve common development.
Automatic granule packaging equipment
| Type: |
Packaging Line
|
Condition: |
New
|
Application: |
Food,Commodity,Medical,Chemical
|
| Packaging Type: |
Bags
|
Packaging Material: |
Plastic
|
Automatic Grade: |
Automatic
|
| Driven Type: |
Pneumatic
|
Voltage: |
220v
|
Power: |
3.4kw/4.2kw
|
| Place of Origin: |
Shandong China (Mainland)
|
Brand Name: |
Guoqiang
|
Model Number: |
GQ-350/450
|
| Dimension(L*W*H): |
4020*770*1450mm/4380*870*1500mm
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
stainless steel: |
spraying plastics
|
|
|
|
|
