Marshmallow packaging machine
1: PLC Control
2: For different sizes
3: Multi-function
MCWB-250X Automatic marshmallow packaging machine
I. Main performance and structure features
1. Double transducer control, flexible bag length cutting, operator needn't to adjust the unloading working, saving time and saving films.
2. human-machine operation, convenient and quick parameter setting..
3. Self diagnosis failure function, clear failure display..
4. High sensitivity optical electric color mark tracking and digital input cut position which makes the sealing and cutting more accurate..
5. Separate PID control to temperature, suitable for various packing materials..
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film..
7. Simple driving system, reliable working, convenient maintenance..
8. All the controls are achieved by software, convenient for function adjusting and upgrading.
MCWB-250X Automatic marshmallow packaging machine
Specification
Type | MCWB-250X | M CWB -350X | MCWB -450X |
Film width | 250MM | 250MM | 250MM |
Bag Length | 65-190mm or 120-280MM | 65-190MM or120-280 MM | 120-450MM |
Bag width | 30-110mm | 50-160MM | 50-180mm |
products High | max.45mm | Max.65mm | max.80mm |
Packing speed | 40-230bag/mins | 40-230bag/min | 40-150bag/min |
Power | 220V 50/60HZ 2.4KW | 220V 50/60HZ 2.8KW | 220V 50/60HZ 2.8KW |
Machine size | 3920x670x1320 | 4020x720x1320 | 4020x870x1450 |
Machine Weight | 500kg | 550kg | 650kg |
Other |
Photos of sample product package
Photos of MCWB-250X Automatic marshmallow packaging machine
Optional Accessories
1:Date Coder 2:Touchable Screen 3:Automatic Punching Device
4:Alternative sealing patterns and notch 5:Auto labeling device 6:Deoxidizer chute device
7:Gas flushing device 8:Alcohol spraying device 9:Auto feeder
The machine will have one year warranty . During the warranty year if any of the parts broken not by man-made.
We will free charge to replace the new one to you . The warranty will begin after the machine send out we received the B/L .
Certificate:
What is Our Advantages?
1. Rapid response on any inquiry.
2. Competitive price.
3. Professional inspection department to guarantee quality.
How to Contact Us?
Send your Inquiry Details in the Below, Click "Send" Now!
Material: |
Plastic,Carbon Steel or Stainless steel
|
Plastic Type: |
BOPP
|
Industrial Use: |
Food
|
Use: |
Snack
|
Feature: |
Disposable
|
Surface Handling: |
Other
|
Sealing & Handle: |
Heat Seal
|
Custom Order: |
Accept
|
Place of Origin: |
Guangdong China (Mainland)
|
Brand Name: |
Ketian
|
Model Number: |
KT-250X
|
Control: |
PLC or Double Drive
|
film thickness: |
18-80um
|
Price terms: |
FOB,EXW ,CIF
|
Film material: |
Laminated film
|
Bag type: |
Pillow bag
|
Marshmallow packaging machine: |
Automatic
|
Speed: |
20-230Bag/Min
|
Shape of sealed bag: |
back seal
|
Other: |
No
|
