Metal Detector With R ejector,India VINSYST price supplier

  VINSYST TECHNOLOGIES is one of the leading manufacturers and exporters of ALL Types of Industrial Metal Detectors extensively used in Varied Manufacturing Industries including the Food, Pharmaceutical, Beverage, Dairy, Spices, Chemical, FMCG, Cement and Textiles Industries worldwide. Our Systems are suitable for All Dry, Wet, Frozen, Hot & High Moisture Content Products.

VinSyst Conveyor Metal Detectors (MDV Series) detect metal contaminants accidently present in any product on a Conveyor line and reject the faulty product. Our Metal Detectors detects all Ferrous and Non-Ferrous metals including Stainless Steel. An automatic Phase Angle function cancels out any variation in product effect caused by the product under inspection.

BENEFITS OF VINSYST CONVEYOR METAL DETECTORS:

Accurate And Reliable Metal Detection

Precise Detection, Even At Maximum Throughput

Simple To Install And Use

Accommodates Quick Product Changes

Suitable For Packs Made From Non-Metal Materials And Metal Materials Too (Aluminum Foil)

Easy To Clean And Maintain

SALIENT FEATURES :

Detecting Theory : Balance Coil / Electromagnetic Induction

Aperture/Tunnel Size Options : 150-1500mm (W)  x  100-600mm (H)

Conveyor Belt Size Options : 80-1450mm (W)  x  500-2000mm (L)

MOC Options : SS 316, SS 304, MS Powder Coated or Aluminium; Non-metallic Parts made from Polypropylene (Food Grade)

Rejection Options : Belt Stop, Air Jet, Pusher, Falling Drop, Belt Compress, Down Flap

FEATURES:

Designed For Control Of Packaged & Unpackaged Goods

Detecting Theory : Balance Coil / Electromagnetic Induction

HACCP, GMP & FDA Approved

MDV-A Series : Detect ALL Ferrous & Non-Ferrous including S.S

MDV-F Series : Detect ALL Ferrous in Foil Packaging

MDV-AF Series : Detect ALL Ferrous in Foil Packaging & ALL Non-Ferrous including SS in Non Foil Packaging (Toggle Switch)

MOC : MS Powder Coated / SS 304 / SS 316, Non Metallic Parts made from Polypropylene (Food Grade)

Display : Analog / Digital / Touch Screen

Advance DSP Technology with Digital Signal Filter

Based on 32 Bit High Speed CPU

Multi Function Operating System

Improved Product “Self-Learning” Functions

Auto PA and Auto Balance

Product Effect Compensation

Automatic Adjustment for Temperature Variation and Static Metal

Multiple Level Password Protection for Safe Use (3 Levels)

Built-in Power Stabilizer

100 Products Preset, Easy to Edit & Recall

RS-232 Interface (Optional)

Data Storage & Data Printout ready

Easy Integration in Existing Production Lines

Adjustable Belt Speed

Imported High Duty Rollers, Belts Sensors, Coils and Motor

Buzzer & Indicator Lamp Alarming

Reject Systems: Belt Stop, Air Jet, Pusher, Belt Compression

Comprehensive Manual with Validation Kits with Certificates for Validation Test

High IP Standards to give maintenance free resistance

Durable for Continuous Working
