Microwave fish maw roasting drying dryer machine,China ADASEN price supplier

Microwave fish maw roasting drying dryer machine

A pplication  R ange :

This machine fits for drying and sterilizing powders, granular, sheet-like or gel-like food, and additive, spices, flavoring, medicine, raw material of herbal medicine, nutritional health products,

agricultural & sideline products, non-fired(or oil savinginstant noodles, noodles, rice powder needles,  soy products, beef jerky, preserved meat, dried fish, tea, tobacco and so on; and for drying, peeling and baking

almond, peach kernel, Groundnut kernels, Chestnut and so on; and for puffing of leisure food, pachyrhizus chips,

potato chips, dried shrimps, fish maw and so on;  and for thawing the frozen fish, poultry; and for drying beans; and

for drying and desulfurating and deoxidizing the metallurgical chemical products; and for drying printing and dyeing

products, ceramics, glass, chemical fiber, cotton yarn, wood, leather, bamboo products, insulation materials,

building materials, wood , cork, alveolate, cardboard,corrugated cardboard, and so on.

Techinical parameters:

  machine f eatures :

1.  Improve  the quality of products ,no cracking,no shrink,no  deformation , insect-resistant ;

2.   Dry ing  and insecticidal  proceed at the same time,good effect;

3.   Drying fast , low energy consumption ,lower the cost,increase efficiency;

4.  No environmental pollution ,particularly applicable to  the production process factories which located in the strict environmental requirements area;

  The Features of Design

1.Transmission System:

  a. Speed of Conveying belt is adjustable. In the transmission system, it applies frequency-converting control of speed, worm gear reducer.

b. The conveyor belt is Teflon Belt,special for microwave.

c. The deviation of belt is adjusted with Hand-movement.

2. The body of the Tunnel

a.The body of the microwave tunnel is made of Stainless Steel. In side there is one set of humidity extraction system to extract the humidity after heating.

b. To be safe, there is Automatic Power-off device while open the door of the machine.

c. The protecting case of Magnetic-pipe and transformer is made of stainless steel. On top there is one set of Heat extraction system to extract the heat energy generated by working of machine.

d.The frame of machine is made of Stainless Steel pipe ,others is made of cold-rolled sheet painted.

e.One set of infrared thermometric is installed at the outlet of the tunnel to measure the temperature.

3.The controlling system

a. On the outside panel there are frequency converting speed controller, emergency stop button, Start, Stop buttons,

b. All the controlling components will be installed into one controlling box, which is at the entrance of the machine.

c.Ordinary button control system,.

d.The microwave power can be adjusted by choosing in the display text.

e. Every microwave source is an independent unit.If one is broken, the machine will not be prevented from running.

f. Every magnetron has an overheating protection device.

Pictures:

  If you are interested in our product-microwave drying&ste rili zation machine,please fell free to talk with us.
