Milk /Juice Plate U.H.T Pasteurizer,China DINGSHUN price supplier

Milk /Juice Plate U.H.T Pasteurizer

FOB Price:Price can be negotiated

Production Capacity:100 Set/Sets per Year for Milk /Juice

Payment Terms: US $6,000 - 20,000 / Set

Update Time:2023-10-25

Contact Supplier

Product Description

Milk /Juice Plate U.H.T Pasteurizer
1. Milk and Juice Sterizlier
2.Automatic working
3.High efficiency
4. CE ISO

Welcome your visit to Zhangjiagang Dingshun Machinery Factory!

Our company specialized in providing complete beverage line machinery for water,juice, carbonated beverage,alcohol and oil.

Milk /Juice Plate U.H.T Pasteurizer

1.The Milk /Juice Plate U.H.T Pasteurizer, as the special one-time Sterilization equipment of milk, fruit juice, beverage or similar fluid and materials, is the ideal equipment to extend quality guarantee period of the materials through sterilization and cooling.

2.Procedure combination design can be done according to the different technique requirements of different materials for heating, sterilization, heat preservation and cooling.

3.In addition, with the features of high automation and stable and precise control, it has various complete protection measures.

4.It is expansively applied for milk, fruit juice, beverage, syrup, sauce, vinegar, fluid with granular and various thick sauces.

Technical parameter

Model:3-Steps

Model	GN-5000
Production capacity(L/H)	5000
Material inlet temperature	5 °C
warm keeping time (s)	4-15
Sterilizing temperature	95-125 ( 138 °C )
Material outlet temperature	4-20
Steam pressure	0.4 ( 0.6mpa )
Steam cost	-400kg/h
Compressed air pressure	0.6mpa
Compressed air consumption	50L/H
Size	5000×2000×2000
Power(kw)	25
Price :	Get latest Price

Why is

milk homogenized?

Condition:	New	Place of Origin:	Jiangsu China (Mainland)	Brand Name:	DINGSHUN
Model Number:	GN-5000	Voltage:	380V	Power(W):	3.5KW
Weight:	2300KG	Dimension(LWH):	500020002000mm	Processing Types:	JUICE/MILK
Processing:	High Temperature Sterilizing,Other	Certification:	CE ISO	Warranty:	12 months
After-sales Service Provided:	Engineers available to service machinery overseas	Name:	Milk /Juice Plate U.H.T Pasteurizer	material:	stainless steel

Other Products

Milk /Juice Plate U.H.T Pasteurizer

Company Profile

Name: Zhangjiagang Dingshun Machinery Factory

Main Products: Water Treatment Machines,Beverage Processing Machines,Filling Machine,Labeling Machine,Packing Machine

Business Type: Manufacturer

Total Employees: 11 - 50 People

Established Year: 2006

Main Markets: Mid East, Domestic Market, Eastern Asia, Southeast Asia, South Asia

Address: No.98 Baixiong Road,Sanxing,Jinfeng Town

Zhangjiagang Dingshun Machinery Factory is located in Yangtze River Delta, Sanxing Industrial Zone District, Zhangjiagang City, which is very close to Shanghai, Wuxi and Nanjing city. Our company is a professional manufacturer of beverage machinery and water treatment equipment. We take markets as orientation, science technology as spirit, quality as life and set up one complete set of service guarantee system. Our company regards reputation as our principle.

At present, our company makes the following production line machinery:
2,000 to 25,000bph complete pure water and mineral water production line machines
2,000 to 25,000bph complete carbonated beverage production line machines
2,000 to 25,000bph fruit juice complete production line machines
1,000 to 10,000bph grape wine and alcohol filling packing line machines
200 to 10,000bph oil filling and packing line machines
2000 to 10,000bph vinegar filling and packing line machines

Our company has imported machines from many countries such as Bangladesh, Chile, Canada, Argentina, Brazil, India, Sri Lanka, Thailand, South Africa, Tanzania, Algeria, Romania, Spain and so on.

Welcome your visit to our company and set up a long term friendly cooperation.
