1. Overwrapping Machine for Chewing Gum
2.Cellophane 3D overapping machine (with tear tape
3.Suitable for DVD,CD,box,comestics
Overwrapping Machine for Chewing gum
Performance Parameter:
Model |
MQD-20B |
MQD-20D |
Packaging speed |
12-25boxes/min |
12-25boxes/min |
Packaging size |
(L)65-270mm(W)60-150mm(H)20-90mm |
(L)100-400mm(W)45-240mm(H)20-115mm |
Machine dimension |
(L)2300mm(W)860mm(H)1670mm |
(L)2180mm(W)1000mm(H)1500mm |
Conveyor dimension |
(L)1650mm(W)450mm(H)950mm |
(L)1600mm(W)270mm(H)770mm |
Weight |
900kg |
800kg |
Total power |
6.5kw |
6.5kw |
Voltage |
3N AC 380V 50HZ |
3N AC 380V 50HZ |
Usage: Functional Features:
This machine is designed on the basis of absorbing,digesting and improving the advanced science and technology from Europe and Japan, using imported PLC control and electric components, which is drived by pneumatic cylinder, the servo motor controls the film falling, the setting and adjustment of the film length could be adjusted freely, at the advantage of stable and reliable operation,high speed,a firm packing, smooth and beautiful. the frame of machine is made up of imported high quality nice aluminium alloy or stainless steel and closed safe glass shield, It could do packing, feeding, folding, heat-sealing, counting and sticky tear tape automatically. malfunction automatic self-diagnosing and alarming, Changing few parts could wrap different specification (dimension, height, width) of different products. Can be used with cartoning machine,save money,reduce human resouce,improve effcet.
Cellophane overwrapping machine is used for wrapping the square, rectangular and even trapezium shaped product with a layer of cellophane paper the same as the packaging of cigarette.
Suitable for single and bundles packaging of various pharmaceuticals, condom, health-care products, confectionery, chewing gum, tea, coffees perfumes, cosmetics, notepad, scratchpad, stationery , eraser, digitalmedia , VCD/DVD/CD cassette, tape, tobaccos, playing cards , napkin paper, etc.
Work Shop:
Warehouse:
Packing:
Shipping:
Detail of Machine:
For more information,please feel free to call us: 0086-18001788503 or visit our website: www.shmooha.com
Type: |
Wrapping Machine
|
Condition: |
New
|
Application: |
Food,Commodity,Medical,Chemical,Boxes
|
Packaging Type: |
Stand-up Pouch,Bags,Foil,Pouch,Boxes
|
Packaging Material: |
Plastic
|
Automatic Grade: |
Automatic
|
Driven Type: |
Electric
|
Voltage: |
220V
|
Power: |
6.5KW
|
Place of Origin: |
Shanghai China (Mainland)
|
Brand Name: |
MH
|
Model Number: |
MQD-20D
|
Dimension(L*W*H): |
(L)2180X(W)1000X(H)1500mm
|
Weight: |
800kg
|
Certification: |
CE
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
packing speed: |
12-25 cases/min
|
packing length: |
100-400mm
|
packing width: |
45-240mm
|
packing height: |
20-115mm
|
