| LONGWAY Overwrapping machine 1.capacity is 45bag per minute 2. auto film cut and sealing, 3.layer auto feeding overwrapping machine
function : bottling beverage(pure water ,mineral water, carbonated beverage, juice) combination package capacity is 45bag per minute
technical parameter facility overall size is L11850*1215*2150H mm shrinkage film material is PE PVC POF shrink membrane thickness is 80~90um per minute max capacity is 45 bag (can limitless speed adjust) power supply max load relied is heating case 48kw/220v(while temperature power is 48KW, working temperature keeping section power is 24kw) mechanism part power is 10KW) machine usage compressor air pressure is 0.4~0.7Mpa max gas consumption quantity is 0.25NM 3 /min Conveyor belt max width is 600mm,height is 1120~1185(mm)(can adjust) pressure requirement is 380/220V facility weight is 5150kg
product description appearance concision,beauty,fracture novel,unique,convenient to maintain big screen, manipulation interface LCD Chinese and English display pneumatic expand support membrane roller, membrane change is quick, membrane change just need two minute membrane tension transport, even and plat, film cutting controlling is precision, cut is tidy; super servo controlling technology can keep each fracture precision in-phase, transmission is reliably heating case fracture is reasonable,heat insulation and warm keeping,temperature controlling precision is highly match Austria B&R,German P+F,German Festo,Italy Motuoliao ect international most advanced controlling component, device is fine, working condition is steadily. mechanism drive part adopt to heating treatment stainless steel or medium carbon steel ect material; surface spray coating quality is fine; whole machine anti-rust character is very highly while all the electricity,pneumatic controlling accord with latest international applied criterion (CE criterion) while electricity cut, set manpower rotary conveyor belt device, easy to move heating tunnel inside product outside wooden case and wrap membrane separately package
|
|
|
|
|
Zhangjiagang Longway Machinery Co., Ltd,is a hi-tech designing & manufacturing enterprise specialized in PET machinery and other kinds of plastic machinery in china. We offer clients from a single machine to a complete production line, our main products include:
automatic stretch blow molding machine
injection molding machine
PET bottle blow mold
3000-36000b/h mineral water & pure water processing and filling line;
3000-36000b/h fruit juice & iced tea hot processing and filling line;
100-2000b/h 5 gallons series bottling lines;
2000-36000b/h carbonated drink processing and cold filling line;
1000-8000b/h vinegar & wine filling and packing line;
Series of plant protein drink processing drink processing and filling lines;
Complete set of combined fruit & vegetable juice (or powder) producing line;
Various of water treatment equipment.
Also we provide turkey solution aiming at
