pasteurization machine,China Xiongwang price supplier

pasteurization machine

FOB Price:Price can be negotiated

Production Capacity:10000 Piece/Pieces per Year

Payment Terms: US $3,000 - 100,000 / Piece

Update Time:2021-06-27

Contact Supplier

Product Description

pasteurization machine
1.High qualification rate
2.High working efficiency
3.Good after-sales service

pasteurization machine

Specification:

The UHT plate-type sterilizer equipment is specially designed for dairy products,fruit juice,beverage and similar liquid Material as one-stage Sterilization equipment.It's an ideal equipment for material to reach the aim of prolonging the time of preserving freshness through sterilization and cooling .According to the various technology request from customes for heating,sterilization,heat-preservation,cooling of various material,we can design various process combination to meet the technological standard and make the equipment have all kinds of safeguard measures,high temperature alarm and reflux.meantime,we can configure high accuracy automatic control system according to the requirement of customers.

1.production capacity:1-10T/H

2.sterilization temperaure:85-137 centigrade.

Model	BS-UHT-1	BS-UHT-2	BS-UHT-3	BS-UHT-4	BS-UHT-5
Product capacityT/h	1	2	3	4	5
Heat exchanging area m2	16	26	38	46	56
Materal inlet temperature ºC	5	5	5	5	5
Materal inlet temperature ºC	5	5	5	5	5
Sterilizing temperature	137	137	137	137	137
137Warmkeeping timeS	4	4	4	4	4
Ice water temperature ºC	1	1	1	1	1
Ice water cos T/h	3	4	6	8	12
Jiont size mm	φ 25	φ 38	φ 38	φ 51	φ 51
Weight kg	980	1080	1160	1350	1680
Size mm	1500 * 1500 * 2000	1900 * 1800 * 2200	1900 * 1800 * 2200	1900 * 1800 * 2200	2600 * 2200 * 2500
power kw	3	4	5	6	6

Condition:	New	Place of Origin:	Jiangsu China (Mainland)	Brand Name:	Xiongwang
Model Number:	BS-UHT	Usage:	Milk	Voltage:	380V/50HZ, customizable
Power(W):	according to different models of machine	Weight:	according to different models of machine	Dimension(LWH):	according to different models of machine
Certification:	CE/ISO	Warranty:	one year	After-sales Service Provided:	Engineers available to service machinery overseas
Brands of Electric Parts:	SIEMENS, MITSUBISHI, etc.
