PET / Glass Bottle Mineral Water Filling Machine for Non Carbonated Drink , Purified Water,China hsfilling price supplier

PET / Glass Bottle Mineral Water Filling Machine for Non Carbonated Drink , Purified Water
FOB Price:Price can be negotiated
Production Capacity:100 sets/year
Payment Terms: T/T L/C
Update Time:2024-05-14
Product Description
Detailed Product Description






PET / Glass Bottle Mineral Water Filling Machine for Non Carbonated Drink , Purified Water


Products Introduction:

The CGF series Wash-filling capping 3-in-1 Machinery is used to mineral water bottling process, purified water, flavored water and other non-carbonated beverage as well. The CGF Wash-filling-capping 3-in-1 machine can finish all the process from empty bottle rinsing, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and high cost effective.


CGF filling machine Character:


1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Siemens Mitsubishi, Schneider, OMRON.

Technical Parameters:


Model

Number of washing
filling and capping

Production capacity
Bottle per hour(0.5L)

Applicable bottle
specifications (mm)

Power(kw)

Dimension(mm)

CGF14/12/5

14, 12, 5

2000-4000

0.25L-2L
D=50-108 mm
H=170-340mm

3.58

2100x1400x2500

CGF18/18/6

18, 18, 6

5000-7000

4.68

2460x1720x2650

CGF24/24/8

24, 24, 8

8000-12000

6.58

3100x2100x2650

CGF32/32/8

32, 32, 8

12000-15000

9.68

3500x2500x2650

CGF40/40/10

40, 40, 10

15000-18000

9.68

4600x1800x2650

CGF50/50/12

50, 50, 12

20000-24000

10.8

5200x4500x3400

CGF60/60/15

60, 60, 15

25000-28000

11.28

6500x4500x3400
