Piston filling machine, fruit filling machine,filling machine, liquid filling machine,China KESI price supplier

Piston filling machine, fruit filling machine,filling machine, liquid filling machine

FOB Price:Price can be negotiated

Production Capacity:9999

Update Time:2012-12-12

Contact Supplier

Product Description

General introduction

The timed flow volumetric filling machines are controlled by the piston to ensure filling precisely. The product bulk supply is pumped into a holding Tank above a set of pneumatically operated valves. Each valve is independently timed by the filler's master computer so that precise amounts of liquid will flow by gravity into the container.

Characteristic

1. within a single filling cycle can satisfy the large load requirement through several times filling.

2. The interface and PLC control system is easy-to-use.

3. A pneumatic valve to protect bottles from nozzle dripping,

4. Servo nozzle height/dive option available

5. No Product/No Fill (suspend operation)

6. No Bottle/No Fill (suspend operation)

7. Downstream Back-up/No Fill (suspend operation)

Specifications

Speed (8 nozzles)	30----80bottles/min
Container Size	50ml----1000ml
Accuracy	≤±0.5%
Power Supply	220,50(V , Hz)
Power	1kw
Air Pressure	0.4MPa----0.6MPa
Air consumption	0.5 m3
Weight	550kg
Dimension	2100mm1640mm1670mm
Special needs upon your request

Other Products

Piston filling machine, fruit filling machine,filling machine, liquid filling machine

Round bottle labeling machine,fruit bottle labeling machine, juice labeling machine

High-speed labeler,high speed labeling machine,Self Adhesive Labeling Machine

Horizontal labeling machine, small bottle labeling, long bottle labeling

Company Profile

Name: Shanghai Ke Si Packing Machinery Co.,Ltd.

Main Products: packing line,filling machine,labeling machine,capping machine,sealing machine,coding machine,printing machine,automatic filling machine,benerage filling machine

Total Employees: 50 ~ 100

Established Year: 1998

Total Annual Revenue: US$1 Million - US$2.5 Million

Main Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe,

Address: 1112 Middle Cheng Liu Road,Shanghai P.R.China

Shanghai Kesi Packaging Machinery Co.Ltd. committed to production of filling machines and related equipments. We have a complete product line such as labeler series, filling machine series, capping machine series, aluminum foil sealing machine series, batch number printing machine and automatic filling line which suitable for both liquid & gel products.

Whether your company is a small start-up business or a corporation or whether you’re looking for a single machine or a complete liquid packaging system, let Shanghai Kesi Machinery’s experienced sales staff work with you to find the right machine for your packaging project.

Our value lies in:
1, We like new challenges. Our experts are looking forward to solve the customers special problems.
2, We offer the best cost-effective equipment. If production a good quality machine is work, then at the same time provide quality machines at reasonable prices is a kind of art.
3, Our experience proved the high-growth of us. We wish our customers to enjoy such high growth.

We confidently look forward to the better future!
