Precise Thickness Testing Apparatus for Food packaging,China labthink price supplier

Precise Thickness Testing Apparatus for Food packaging

FOB Price:Price can be negotiated

Production Capacity:10 set/month

Payment Terms: t/t

Update Time:2024-10-02

Contact Supplier

Product Description

Labthink CHY-CA Thickness Testing Apparatus is a precise thickness tester, which is based on contact method to measure thickness of films and foils for QC usage. The contact pressure and areas are designed according to internationa standards.

Precise Thickness Testing Apparatus for Food packaging

Applications

Plastic Films, Sheets and Diaphragms Thickness Measurement

Paper and Paper Board Thickness Measurement

Foils and silicon Wafers Thickness Measurement

Metal Sheets Thickness Measurement

Textiles and Non-woven Fabrics, e.g. baby diapers, sanitary towel and other sheeting

Solid Electrical Insulating Materials

Plastic Films, Sheets and Diaphragms Thickness Measurement
Paper and Paper Board Thickness Measurement
Foils and Silicon Wafers Thickness Measurement
Metal Sheets Thickness Measurement
Textiles and Non-woven Fabrics, e.g. baby diapers, sanitary towel and other sheeting
Solid Electrical Insulating Materials

Standards

This Thickness Testing Apparatus conforms to ISO 4593, ISO 534, ISO 3034, ASTM D374, ASTM D1777, TAPPI T411, JIS K6250, JIS K6783, JIS Z1702, BS 3983, BS 4817, GB/T 6672, GB/T 451.3, GB/T 6547

Features

Labthink CHY-CA thickness Testing Apparatus has the following merits:

Automatic lifting presser foot facilitates to minimize system errors that caused by human factors during the test
Manual or automatic operating mode for convenient test
Automatic specimen feeding, specimen feeding interval, number of testing points and specimen feeding speed could be preset by the user.
Display the real-time data of maximum, minimum, average and standard deviation value for data analysis
Automatic statistics and printing functions are available which is convenient for the user to obtain the test results

Technical Specifications

Items	Specifications
Test Range	0~2 mm (standard) 0~6 mm, 12 mm (optional)
Resolution	0.1 μm
Test Pressure	17.5±1 KPa (film) 50±1 KPa (paper)
Contact Area	50 mm ² (film) 200 mm ² (paper) Note: Select one presser foot for film or paper; Customization is available
Specimen Feeding Interval	0 ~ 1000 mm
Specimen Feeding Speed	0.1 ~ 99.9 mm/s
Instrument Size	461 mm(L) x 334 mm(W) x 357 mm(H)
Power Supply	AC 220V 50Hz
Net Weight	32 Kg
