New Type in 2014 Longway Full Automatic Juice Making Machine
Specifications
1.The ORANGE JUICE filling machine is mainly used for bottling juice ,such as Apple Juice ,mango juice ,orange juice and other fruit juice. It can also be used for bottling water ,such as pure water and mineral water.
2.The orange juice filling machine includes washing part ,filling part and sealing part all of the process is automatic.
3. It adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and more east.
4. The advanced OMRON programmed controller (PLC) is adopted to control the machine to run automatically,
5. Transducer is uesd in bottle entering chains to adjust speed to make the operation of moving bottle steadily and reliably.
6. It is convenient to operate with higher automation because every part of the machine is inspected to run with photo electricity.
7. The Orange juicefilling machine can be produced according to your requirement, because we are professional beverage processing manufacture.
8.It can do the bottles from size 300ml to 2500ml. And little spares are need when changing bottles. We suggest users to take same specification bottles, especially the same bottle neck.
New Type in 2014 Full Automatic Juice Making Machine
Parameters
| Model |
CGFR8-8-3 |
CGFR16-12-6 |
CGFR18-18-6 |
CGFR24-24-8 |
CGFR32-32-10 |
CGFR40-40-10 |
CGFR50-50-12 |
| Rinsing Head No |
8 |
16 |
18 |
24 |
32 |
40 |
50 |
| Filling Head No |
8 |
12 |
18 |
24 |
32 |
40 |
50 |
| Capping Head No |
3 |
6 |
6 |
8 |
10 |
12/10 |
12/10 |
| RatedCapacity (500ml) |
2000BPH |
4000BPH |
7000-8000BPH |
10000-12000BPH |
12000-15000BPH |
15000-18000BPH |
20000-22000BPH |
| Overall Size |
1900*1420*2000mm |
2200*1600*2300mm |
2450*1900*2300mm |
2750*1180*2400mm |
4000*2300*2300mm |
4550*2650*2300mm |
5450*3210*2300mm |
| Weight |
1.5T |
2.2T |
3.0T |
4.0T |
8.0T |
12.0T |
20.0T |
| Power(KW) |
3.0kw |
3.5kw |
4.0kw |
4.8kw |
7.6kw |
8.3Kw |
9.6Kw |
| Rated Voltage |
380V |
380V |
380V |
380V |
380V |
380V |
380V |
New Type in 2014 Full Automatic Juice Making Machine
We have complete fruit juice processing machine from A to z .
|
|
|
|
Zhangjiagang Longway Machinery Co., Ltd,is a hi-tech designing & manufacturing enterprise specialized in PET machinery and other kinds of plastic machinery in china. We offer clients from a single machine to a complete production line, our main products include:
automatic stretch blow molding machine
injection molding machine
PET bottle blow mold
3000-36000b/h mineral water & pure water processing and filling line;
3000-36000b/h fruit juice & iced tea hot processing and filling line;
100-2000b/h 5 gallons series bottling lines;
2000-36000b/h carbonated drink processing and cold filling line;
1000-8000b/h vinegar & wine filling and packing line;
Series of plant protein drink processing drink processing and filling lines;
Complete set of combined fruit & vegetable juice (or powder) producing line;
Various of water treatment equipment.
Also we provide turkey solution aiming at
