Red Wine Filling Capping Machine CE standard,China JND price supplier

Red Wine Filling Capping Machine CE standard

FOB Price:Price can be negotiated

Production Capacity:1000 Piece/Pieces per Year

Update Time:2024-11-02

Contact Supplier

Product Description

RED WINE Filling Capping Machine
CE standard
Output:2000-10000BPH
After-sales service:One year
PET&Glass bottle optional

Red Wine Filling Capping Machine

Product Description

Application

This series equipment is used in the production of red wine, also for mineral water and purified water, etc.

Filling and capping are integrated into one machine.

Features:

1. The suspending bottle-neck clamping design make the bottle stable during the high-speed moving conditions. By changing a few parts, it can meet the need of production of different types of bottles easily.

2. The special stainless steel clip is adopted and the clip will not contact the area above the bottle's screw thread. Nozzle is in the clip can guarantee the complete wash of the interior of the bottle.

3. The advanced gravity filing technology used in this machine make the filling quickly, steady and accurate.

4. Magnetic torque is used for screw capping. And the power of screw capping can be adjusted freely. Capping is reliable and will not harm the caps.

5. Advanced technologies, such as human-machine interface touch-screen and PLC program control are adopted in this machine.

6. All parts that contact with the water are made of high quality stainless steel. The critical electrical components are from famous international companies. Such as Mitsubishi, Omron etc

Model	JND 14-12-5	JND 16-12-6	JND 18-18-6
Production Capacity ( BPH )( 500ml )	3000-4000	4000-6000	6000-8000
Filling Pressure ( Mpa )	≤0.4
Applicable Bottle Type	(BottleDiameter)Φ50-100mm(Height)150-320mm (Volume)250-2000ml
Applicable Cap Shape ( Mpa )	Plastic Screw Cap
Gas Source Pressure ( Mpa )	0.6
Gas Consumption ( m3/min )	0.2	0.25	0.3
Total Power ( kw )	4.6	4.8	5.03
Total Weight ( kg )	2500	3500	4200
Dimension ( LWH )( mm )	235017002030	240018502030	283020302030

Packaging & Shipping

Wooden case

Company Information

J&D Water is China Leading Water Bottling Equipment Manufacturer.

J&D company can supply following complete set of drink ing equipment:

water dispenser, water filter system and all of accessory equipments for drink plant

3000-36000BPH mineral water & pure water processing and filling line;
3000-36000BPH fruit juice & iced tea hot processing and filling line;
100-2000BPH 5 or 3 gallons series bottling lines;
2000-36000BPH carbonated drink processing and cold filling line;
1000-8000BPH vinegar & wine filling and packing line;
Various of water treatment equipment.

Any more information, pls feel free to contact us. We will reply you no more than 24 hours.

Type:	Filling Machine"> Filling Machine	Condition:	New	Application:	Beverage,Wine
Packaging Type:	Bottles	Packaging Material:	Plastic,Glass	Automatic Grade:	Automatic
Driven Type:	Pneumatic	Voltage:	380V	Power:	4.6 KW
Place of Origin:	China (Mainland)	Brand Name:	JND	Model Number:	JND18186
Dimension(LWH):	2350mm1700mm2030mm	Weight:	2500 KG	Certification:	CE
After-sales Service Provided:	Engineers available to service machinery overseas

Company Profile

Name: Shenzhen J&D Drinking Water Equipment Co., Ltd.

Main Products: Filling Machine,Labeling Machine,Shrink Labeling Machine,Package Machine,Water Treatment Equipment

Business Type: Manufacturer, Trading Company

Total Employees: 51 - 100 People

Established Year: 2008

Main Markets: South Asia, Southern Europe, Northern Europe, Central America, Western Europe

Address: Unit 810-811, Cyber Times Tower A, Tianan Cyber Park, FuTian District, ShenZhen, 518040, China

ShenZhen J&D Drinking Water Equipment Co., Ltd. is China's leading manufacturer of bottling equipment and supply the global market with a complete range of bottling equipment and accessories.

J&D Water with fixed assets of over 80 million $ u.s. and a global turnover of over 500million $u.s. employ 1500 staff in the design, manufacture and sales of their range of bottling equipment. The total manufacturing and administration area owned by J&D is over 70,000 sq meters.

J&D Water are ISO9001 approved and all of the equipment manufactured by J&D is manufactured to the following standards CE, TUV, GS, ETL, UL, SASO, RoHS and CSA.

J&D Water operates a program of continuous improvement in the design and quality of their equipment and where appropriate utilizes advanced filling technologies from Germany, USA and Italy.

J&D Water can supply the following equipment:

* water dispensers, water filtration systems and all associated equipment required for a bottling factory including bottle blowing, labeling and packaging equipment.

*3000-36000BPH mineral water & pure water processing and filling lines;

*3000-36000BPH fruit juice & hot drinks filling lines;

*100-2000BPH 5 or 3 gallon bottling lines;

*2000-36000BPH carbonated drink processing and cold filling lines;

*1000-8000BPH vinegar, wine, oil filling and packing lines;

* A full range of water treatment equipment.

With world leading technologies and a program of continuous improvement, all the products supplied by J&D Water have gained a good reputation from their global customer base. J&D have exported bottling and associated equipment to the USA, UK, Ireland, Canada, Australia, Mexico, Russia, Africa, the Middle East area etc for over 10 years. J&D Water can assist with factory layouts and can also provide a full installation and technical back up service. more
