ROPP Fully Automatic Beverage Bottle Capper Machine for Beer Filling Plant 0.4 - 0.6Mpa,China HSfilling price supplier

ROPP Fully Automatic Beverage Bottle Capper Machine for Beer Filling Plant 0.4 - 0.6Mpa

FOB Price:Price can be negotiated

Production Capacity:200sets/year

Payment Terms: T/T L/C

Update Time:2025-01-16

Contact Supplier

Product Description

Detailed Product Description

ROPP Fully Automatic Beer Bottle Capper Machine for Beer Filling Plant 0.4 - 0.6Mpa

Quick Detail:

automatic bottle capper machine ROPP cap

1. Automatic screw capping machine

2. Good look, easy to operate

3. High speed capping

4. Stable capping

Description:

This automatic bottle capper machine ROPP cap is developed on the basis of foreign technology. The structure is compact and the production is stable. The machine has the function of self-protection and the glass bottle will not be broken. The capping speed can be adjusted to control the production capacity.Corks are squashed to the desired diameter and then punched into bottles. The squashing from the corks releasing applied around the corks, avoiding residua from the corks releasing to the bottles.Automatic cork loading device is associated with the machines, and efficiency is then improved.The middle pillar holding every individual cork capper is adjustable to fit the height (250mm-370mm)of the bottles.The diameter of the corks is allowed to be from 20.5mm to 24mm, and the height of corks is allowed to be 35mm-44mm.Clutch protection device is used with the automatic bottle loading device automatically give warning whenever unusual situations appear.Photo electric switches are used to detect bottles, No corks are provided if no bottles are detected.Allowable diameter of bottles is from 60mmto 90mm.

Applications:

This machine is used for plastic lid screw capping process. it Suitable for PET bottles and glass bottles.

Specifications:

Model	XF-102
Applied bottle range	50-1000ml
Applied cap size	12-70mm
Yield of capping	>=99%
Power Supply	220V 50HZ
Power Consumption	<=2KW
Pressure	0.4-0.6Mpa
Speed Control	Frequency Convertion
Single machine noise	<=70Db
Weight	About 850kg
Dimension(LxWxH)	2000x1100x2600(mm)
Production Capacity	5000-7200 bottles/h

Competitive Advantage:

1. The convenient construction adjustment system is equipped with precise ruler
and counter
2. The torque limiters can ensure the torque consistency effectively
3. The mainframe can be lifted and descended automatically by a motor
