SLA-304 Labeling System For Vials Bottle

FOB Price:Price can be negotiated

Payment Terms: EXW / FOB / CIF

Update Time:2022-08-25

Contact Supplier

Product Description

Main Technical Parameter:

Model No.	SLA- 304 Rotary labeling system for vials
Bottle Type & Size	Round bottle ,Diameter: Φ13-28mm
Labeling Speed	500-600/bpm ( Related to the Bottle size/ Label type)
Stop Label Precision	±0.3mm
Labeling Precision	±0.5 mm
Use environment Temperature	5-45℃
Use environment humidity	15-90% (non-condensing )
Width of Conveyer belt	Standard
Machine Outer Size (mm)	*(L):2870mm(W)1060mm(H)1800mm*

Machine’s Power : 230V50Hz/60Hz ( Customize optional )

Main Application :

Application : specially designed for high speed and high precision labeling on vials and other small round bottle

Product Details:

Type: Labeling Machine
Condition: New
Application: Medical/pharmaceutical ,
Driven Type: electric & pneumatic
Automatic Grade: Automatic
Voltage: 230V50Hz ( optional )
Packaging Type: Bottles
Packaging Material: Seaworthy wooden case
Brand Name: Shell-conning
After-sales Service Provided: Engineers available to service machinery overseas

formances and features:

1:Humanized touch screen can be stored into the 50 groups of labeling parameters, simple operation, intuitive, with rich online help function and broke-down display function

2,Store 50 groups labeling parameters: according to different objects or labels can be set in advance and storing the parameters, can be use directly, do not always set the parameters.

3, The power of belt make the labeling more accurate positioning.

4, Can flexible selecting the thermal transfer printing, hot printing machine or

spurts the code machine, complete synchronization code marking and labeling. (Optional )

5,Can increase the vision detection system, automatic detection of print date and batch number etc.. Effectively prevent leakage label roll, wrong labeling caused problems such as paste, repeat stick.

6, The label of intelligent management, the label soon used up alarm or shutdown.

7, The device adopts imported high torque small inertia servo motor drive, the Swiss diamond sand roller technology, never deformation, friction is excellent, large angle to determine the characteristic of nonskid ensures high precision operation give mark function. The world famous brands imported electrical components, ensure the stability and reliability.

Company Profile

Name: Shell-Conning Mechanical Equipment Co.,Ltd

Main Products: labeling systems,packaging systems,The entire line of integrated systems,other ancillary equipment

Business Type: Manufacture & Trade & Service

Total Employees: 50 ~ 100

Established Year: 2010

Total Annual Revenue: US$2.5 Million - US$5 Million

Main Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe,

Address: 5/F Zhonghang Building ,Chuangye Road 10,

Guangzhou Shell-Conning Mechanical Equipment Co.,Ltd.which is located in the Guangzhou Economic and Technological Development Zone, for the production of high-end automatic labeling machines and on the downstream supporting professional equipment manufacturers, production, research and development, sales and service in one, for medicine, food, cosmetic, chemical, electronics, information and tobacco industries to provide a full range of automatic labeling solutions and customized services
