According to the need of the experiment, spiral-wound membrane equipmentcan be used with microfiltration, ultrafiltration, nanofiltration, reverse osmosis and other types of spiral-wound membrane components. It can be used for the concentration of liquid, desalination, decolorization, purification, clarification, sterilization and other technological experiments. It has been widely used in pharmaceutical, food and beverage, chemical, plant extracts, environmental water treatment and other fields.
Expected spiral-wound membrane experimental equipment features:
l Simple and practical technology with a beautiful exterior;
l Simple installation and user-friendly maintenance;
l Convenient and stable operation;
l Stainless steel, corrosion-resistant, and long service life;
l Compact design and small size;
l Small cycle volume, less supply material, and good separation;
l Reliable experimental parameters, which can be used as a reference for industrial design;
l Easy to clean and durable membrane core;
l Equipment design pressure up to 40 bar, which can be applied to a wide range of research; and
l 4 in 1 multi-function equipment, and can be used with reverse osmosis, nanofiltration, ultrafiltration, and microfiltration membrane core
Expected film core and accessories features:
l Imported film core with reliable quality;
l Full range of products, with reverse osmosis, nanofiltration, ultrafiltration, and microfiltration membrane core;
l Special film core with high temperature, solvent r, and acid resistance;
l ‘Easy to clean and recoverable film core;
l High pressure pump made from internationally renowned brands;
l Constant system flow with stable and reliable experimental results;
l Standard accessories, which are generic and easy for maintenance; and
l More than 20 kinds of professional film cleaning agent with excellent cleaning effect
| Roll membrane test equipment
|
Basic performance parameters
|
||
| Model
|
GCM-S-02
|
GCM-S-20
|
|
| Film specifications
|
1812
|
2540
|
|
| Membrane area (m2)
|
0.24
|
1.77-2.4
|
|
| Maximum working pressure (bar)
|
40
|
40
|
|
| Optimal operating temperature (℃)
|
10-45
|
10-45
|
|
| Optimal pH range
|
2-12
|
2-12
|
|
| Minimum circulating volume (L)
|
0.6
|
8
|
|
| Total power (kw)
|
1.5
|
4
|
|
| Overall dimensions (m)
|
0.68×0.40×0.85
|
1.40×0.70×1.12
|
|
Typical application:
l Microfiltration membrane clarification;
l Suspended solids elimination;
l Ultrafiltration membrane decolorization, protein elimination, getting rid of ash by concentration;
l Nanofiltration membrane desalination and concentration;
l Reverse osmosis membrane concentration;
l Sugar and alcohol refinement and purification;
l Beverage clarification and juice concentration;
l Extract active ingredient from animal and plant suspension;
l Enzyme preparation, protein concentration and separation;
l Dye desalting enrichment;
l Whey separation and concentration;
l Stock recovery: purification of MSG stock, and glucose crystal stocks;
l Water purification pretreatment;
l Quality water supply by nanofiltration ultrapure water preparation and so on;
l Wastewater treatment and water reuse
l Other filtration and separation.
GUOCHU TECHNOLOGY (Xiamen) Co., Ltd. is a high-tech enterprise focusing on membrane technology as the core technique, dedicating to the development of new purification technology, for the biological pharmaceutical, food and beverage, fermentation industry, deep processing of agricultural products, plant extraction, petroleum and petrochemical industry, water treatment, air cleaning, chemical industry and other industries to provide comprehensive filter service and purification solution to fit the personalized requirement from different customers.
