TBWG100 chocolate melting machine,China TIAN FANG price supplier

TBWG100 chocolate melting machine

FOB Price:Price can be negotiated

Production Capacity:100 Set/Sets per Year

Update Time:2023-04-15

Contact Supplier

Product Description

chocolate melting machine
1.capacity:100L
2.power:370w
3.double water jacketed, electric Heater
4.with agitator

Product Description

USE:

1. This chocolate melting machine is used for storage of fine grinded chocolate paste to keep required temperature of chocolate. The temperature control system in machine can keep required temperature of chocolate by control temperature of water in jacket layer.

2. Chocolate melting machine has functions of temperature decrease, rise and keeping; you can set required temperature on control panel.

3. Meantime, it also has functions of degasification, desmelling, dehydration and preventing the chocolate paste from separation of chocolate fat by continuous stirring of agitator.

Main Parameter:
Model:TBWG100

Maximum capacity:100L

Motor power:370w

Heater power: 3kw

Rotation speed of agitator:24round per minute

Net weight: 150kg

Dimension : (Diameter)700*(Height)1250mm

Adjustable Temperature controller

Double Water-jacket layers,water heated by eletrical heater.

Material: All stainless steel.

Also,we can make chocolate tank with capacity from 100L to 5000L.

Model of product	Maximum capacity(L)	Motor power(kw)	Net weight (kg)	Outside dimension (mm)
TBWG5000	5000	7.5	3000	φ 2000*2710
TBWG3000	3000	5.5	2000	φ 1700*2500
TBWG2000	2000	3	1500	φ 1400*2500
TBWG1000	1000	2.2	1000	φ 1220*1850
TBWG500	500	1.5	600	φ 1000*1380
TBWG300	300	1.1	200	φ 900*1250
TBWG200	200	1.1	180	φ 800*1250
TBWG100	100	0.37	150	φ 700*1250

Packaging & Shipping

1. Strong seaworthy wooden package.

2. Protection against humidity.

3. Skilled capability of delivery to your country.

Guarantee & After-Sales Services

1. One-year guarantee period for complete machine.

2. Free charge of Accessories within guarantee period excluding false operation.

3. Free charge of layout design, instruction with details, installation guide and local team training.

4. Experienced engineer is available to set up the machines upon request.

5. 24 hours technical support service by email and mobile.

Company Capability

Condition:	New	Place of Origin:	Jiangsu China (Mainland)	Brand Name:	TIAN FANG
Model Number:	TBWG100	Application:	Chocolate	Voltage:	Customized
Power(W):	370w	Weight:	150kg	Dimension(LWH):	700mm(diameter)X1250mm(height)
Certification:	CE	Warranty:	One year	After-sales Service Provided:	Engineers available to service machinery overseas
Capacity:	100L	Material:	All stainless steel	Water jacket:	Yes
Type of heater:	Electric heater	Heater power:	3kw	Rotation speed of agitator:	24 round per minute
Name of machine:	chocolate melting machine
