Tilting jacketed steam kettle with agitator /mixing kettle,China DF price supplier

Tilting jacketed steam kettle with agitator /mixing kettle

FOB Price:Price can be negotiated

Production Capacity:50 Sets per month

Payment Terms: US $ 2,000 - 8,000

Update Time:2024-09-26

Contact Supplier

Product Description

Name: Tilting jacketed steam kettle with agitator /mixing kettle

Application:

Stainless steel double-layered kettle is also called double- Jacketed steam cauldron, which is applied widely for the process- ing such products as candy, medicine, dairy, alcohol, cake, beverage, sweetmeat etc. It is also used to boil water, cook, stew, boil Porridge etc in great scale dinning-room or eatery.

which is a choiceness equipment in food processing to advance quality, shorten time, improve labor condition.

Characteristics:

1. Efficient Heating

Steam heating jacketed kettle takes a certain pressure of steam as heat source. It has characteristics such as big heating area, uniform heating, high thermal efficiency, short boiling time, easy control of the heating temperature etc.

2. Safety and Convenience

Steam heating jacketed kettle adopts stainless steel 304 as production material, which is resistant to heat and acid. The machine is equipped with pressure gauge, safety valve or electrical control box. Not only has good-appearance, but also easy to install and operate. It is safe and convenient.

Technical parameters:

Name	steam heating jacketed kettle
Working capacity	50L-600L
Parameters	-All parts contact material is made of SUS316 material -Full jacket for steam heating design pressure:0.2-0.3MPa design temperature:146 °C -Rockwool insulation:50mm, Outer layer:SUS304 -External surfaces is Satin Polishing.3A finished -Semi-Open cover, Stirring speed:30-36rpm Work pressure: Inner 0.09MPa Inner design temperature ≤137C° Structure:180º tilting Thickness: in:§=4mm, jacket: §= 4mm Heating type: steam heating Can be anchor Mixer with scrapers for viscosity liquid, Pressure vessel Certificates can be supplied -other Accessories: exhaust valve, pressure meter, safely valve, mixing device, CIP cleaning head, thermometer etc.
Package	Export wooden case or as customer's demand
Crate dimension(LWH)	According Specific Requirement
Payment	TT, L/C
Port of shipment	Ningbo
Delivery time	Within 20-30days after down payment

Pictures:

Tilting jacketed steam kettle with agitator /mixing kettle

Our Factory:

Tilting jacketed steam kettle with agitator /mixing kettle

Zhejiang Dafeng Light Industrial Industrial Machinery Co.,Ltd can provide our customers with high quality stainless steel Chemical Reactors with agitation to process product. These tanks with high pressure resist,high temperature resist for dye,paper,pharmaceutical,and other chemical process industries,standards meet to national pressure vessel manufacture requirements.

Other Products

Hot sale of complete beer making equipment

Hotel draft beer fermentation tank

Hot sale of Red copper brewery for brewpub

Hot sale of 20hl beer brewery equipment

Company Profile

Name: Wenzhou Advanced Technology Machinery Co., Limited

Main Products: Food processing machine,Pharmaceutical Equipment and Fluid project

Business Type: Manufacture

Total Employees: 20 ~ 50

Established Year: 2008

Total Annual Revenue: US$2.5 Million - US$5 Million

Main Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe,

Address: Room 301, No. 2109, Yongqiang Avenue, Longwan District, Wenzhou, Zhejiang, China (Mainland)

Wenzhou Advanced Technology Machinery Co., Limited can provide our customers with high quality stainless steel food processing/beverage/chemical processing equipment. These tanks are made of stainless steel 304,316L etc,for dye,paper,pharmaceutical,beer and so on,standards meet GMP,and pressure meets national pressure vessel manufacture requirements.
