Liaoning Zhanhongtu Machinery & Equipment Co.,Ltd
Fast speed: high glossy and normal workpiece enters the host and comes out within a working period of 2 minutes. It is 2 -4 times than one normal negative vacuum membrane press machine.
The effect is good: the normal pvc film vacuumed products have clear grooves in place, no open edges, no foaming, no color difference, high gloss pvc film workpiece surface strong adhesion, and the effect reaches the international leading level.
Low power consumption:this machine main heating power is 28KW, only half of other factory machine,main heating start-up power is 18KW ,average consume power is 10kw/h
High configuration: this machine main accessory use the germany, japan, Taiwan original brand, high configuration and character stable.
Main technical parameter
| Overall size
|
11200*2480*2150mm
|
voltage
|
380v 50hz 3 ph
|
| Working table size
|
2560*1270mm
|
Net weight
|
14000kgs
|
| Max working height
|
50 mm
|
Hydraulic system
|
TAIWAN
|
| Working pressure
|
Positive press ≥0.6mpa negative press≥-0.095mpa
|
Motor power
|
28kw
|
| Machine frame
|
Total steel plate cutting
|
Oil cylinder structure
|
solid
|
| Hydraulic system
|
taiwan
|
Oil cylinder diameter
|
180mm
|
| Vacuum pump
|
Imported
|
Oil cylinder stroke
|
200mm
|
| Heating type
|
Electrical heating(nanotechnology)
|
|
|
LIAONING ZHT MACHINERY CO.,LTD is one special produce the profile shapes surface machines,now we have the worker more than 100 people,our factory area 30000 square meters. Our machines covered china and all over the world. In the past ten years, ZHT center on the customers, basic the market requirement sustaining innovation , win our customers respect and trust.
We keep the idea for the customer creating value and wealth. Our company through many years work hard, building strong development and research group, we have reached the world leading level in the area of membrane effect,energy consumption and performance configuration . we have developed all kinds of high end performance vacuum membrane press machine. We have all kinds of models, it is widely used to cabinet vacuum,solid wood surface cabinet, solid wood composite doors, pvc doors, panel furniture ,profile wrapping machines.
Our products have passed CE certificate . we have sold to Europe, America , southeast asia, Africa and so on, more than ten countries and areas.
LIAONING ZHT MACHINERY CO.,LTD special produced the high glossy PVC film vacuum membrane press machine, positive and negative press membrane machines ,we have satisfied our customers requirements and give more best effect for our customers product.
LIAONING ZHT MACHINERY CO.,LTD in core idea with “multi win symbiosis,great development, produce the world leading special shape surface machine “we still rely on technical innovation purpose, good service consciousness, keep on carving aspire, refine on attitude . produce the high quality vacuum membrane press machine.
LIAONING ZHT MACHINERY CO.,LTD base on of the customers requirement and supply good sale before and after service for the customers. We have builded good reputation. We get good public praise from our customers and colleagues .ZHT will develop more new type product in the future, we will let ZHT to the world leading brand.
