Liaoning Zhanhongtu Machinery & Equipment Co.,Ltd
Machine features:
Fast speed: normal workpiece enters the host and comes out within a working period of 2 minutes. The effect is good: the normal pvc film vacuumed products have clear grooves in place, no open edges, no foaming, no color difference, high gloss pvc film workpiece surface strong adhesion, and the effect reaches the international leading level.
Low energy consumption: the total power of the machine is 43kw, it is one one-half copare other factory equipment. The main heating power is 18KW, the average power consumption is 13kw/h, and the configuration is very high: the main components of the machine are made in Germany, Japan, and Taiwan. High configuration and stable performance.
High work efficiency: This machine use fully automatic top block, which saves the process that produce the bottom pad and saved raw material cost , saves the process raw material cost, saves the equipment's pad scanning action sequence, and saves the laminating process Time, greatly improve work efficiency and reduce labor costs.
High automation: This machine is equipped with automatic fabric selection roll-over stand and automatic film cutting device, automatic pad device, press laminating device, tray lifting device and finished product reversing device, etc., high automation, production process smooth, compact, one-stop style vacuum membrane process production.
Main technical parameter
| Overall size
|
13800(11800)*5200*2820mm
|
voltage
|
380v 50hz 3 ph
|
| Working table size
|
3000(2560)*1270mm
|
Net weight
|
24000kgs
|
| Max working height
|
80mm
|
Hydraulic system
|
TAIWAN
|
| Working pressure
|
Positive press ≥0.55mpa negative press≥-0.095mpa
|
Motor power
|
43kw
|
LIAONING ZHT MACHINERY CO.,LTD is one special produce the profile shapes surface machines,now we have the worker more than 100 people,our factory area 30000 square meters. Our machines covered china and all over the world. In the past ten years, ZHT center on the customers, basic the market requirement sustaining innovation , win our customers respect and trust.
We keep the idea for the customer creating value and wealth. Our company through many years work hard, building strong development and research group, we have reached the world leading level in the area of membrane effect,energy consumption and performance configuration . we have developed all kinds of high end performance vacuum membrane press machine. We have all kinds of models, it is widely used to cabinet vacuum,solid wood surface cabinet, solid wood composite doors, pvc doors, panel furniture ,profile wrapping machines.
Our products have passed CE certificate . we have sold to Europe, America , southeast asia, Africa and so on, more than ten countries and areas.
LIAONING ZHT MACHINERY CO.,LTD special produced the high glossy PVC film vacuum membrane press machine, positive and negative press membrane machines ,we have satisfied our customers requirements and give more best effect for our customers product.
LIAONING ZHT MACHINERY CO.,LTD in core idea with “multi win symbiosis,great development, produce the world leading special shape surface machine “we still rely on technical innovation purpose, good service consciousness, keep on carving aspire, refine on attitude . produce the high quality vacuum membrane press machine.
LIAONING ZHT MACHINERY CO.,LTD base on of the customers requirement and supply good sale before and after service for the customers. We have builded good reputation. We get good public praise from our customers and colleagues .ZHT will develop more new type product in the future, we will let ZHT to the world leading brand.
