TQJJ175-1 chocolate bar machine,China TIAN FANG price supplier

TQJJ175-1 chocolate bar machine

FOB Price:Price can be negotiated

Production Capacity:100 Set/Sets per Year

Update Time:2014-09-28

Contact Supplier

Product Description

TQJJ175-1chocolate bar machine
1.capacity:100-300kg/hour
2.power:17.4kw
3.weight:3500kg
4.size:16000x1000x1800mm

Product Description

USE:

1. This automatic chocolate bar machine have all functions of pre-heating empty mould , depositing chocolate into mould , vibrating chocolate in mould , cooling chocolate in mould , de-moulding chocolate from mould and conveying chocolate to next station automatically.

2. In this automatic chocolate bar machine, you can produce following types of chocolate:

- pure chocolate

- center filling chocolate

- two color chocolate

- nuts mixed chocolate (nuts feeder unit required)

- Wafer chocolate (wafer inserter unit required)

3. Real chocolate and compound chocolate are both workable to make in this machine.

Main parameter:

Model:TQJJ175-1

Quantity of depositor:1

Production capacity:100kg/hour~300kg/hour

Capacity of cooling compressor:10HP

Brand of cooling compressor:COPELAND

Temperature in cooling tunnel:5 °C-10°C

Cooling time:18-30 minutes
Power of machine:17.4kw

Size of mould:280x200x30mm

Quantity of mould:280 pieces
Weight of machine:3500kg

Size of machine: 16000x1000x1800mm (LxWxH)

We have automatic chocolate bar machine with 1 depositor (model: TQJJ175-1), 2 depositors (model: TQJJ175-2) and 3 depositors (model: TQJJ175-3). Also we have semi-automatic chocolate bar machine without cooling tunnel (model: TQJJ150).

Model		TQJJ175-1	TQJJ175-2	TQJJ175-3	TQJJ150
Number of Depositor		One	Two	Three	One
Capacity(kg per hour)		100 - 300kg/hour	100 - 300kg/hour	100 - 300kg/hour	200kg/hour
Capacity of Compressor		10HP	15HP	15HP	-
Brand of Compressor		COPELAND	COPELAND	COPELAND
Temperature in Cooling Tunnel		5 - 10°C	5 - 10°C	5 - 10°C
Power(kw)		17.4	23	31.5	7.47
Size of Mould (L×W×H, mm)		280×200×30	280×200×30	280×200×30	275×175×25
Quantity of Moulds(pieces)		280	340	410	200
Net Weight of Machine(kg)		3500	4300	5200	500
Size of Machine (L×W×H, mm)		16000×1000×1800	17000×1000×2300	19000×1000×2350	4300×520×1500
Type of Chocolate	Pure Chocolate	√	√	√	√
	Center Filling Chocolate	√	√	√	√
	One Color Chocolate	√	√	√	√
	Two Color Chocolate (left &right)	√	√	√	√
	Two Color Chocolate (up &down)	-	√	√	-
	Three Color Chocolate	-	-	√	-
	1kg Industrial Chocolate	-	√	√	-
	Nuts Mixing Chocolate	√	√	√	√
	Wafer Chocolate	√	√	√	√

Company Capability

Condition:	New	Place of Origin:	Jiangsu China (Mainland)	Brand Name:	TIAN FANG
Model Number:	TQJJ175-1	Application:	Chocolate	Voltage:	Customized
Power(W):	17.4 kw	Weight:	3500 kg	Dimension(LWH):	16000 x 1000 x 1800 mm
Certification:	CE	Warranty:	One year	After-sales Service Provided:	Engineers available to service machinery overseas
Production capacity:	100kg/hour - 300kg/hour	Capacity of compressor:	10HP	Brand of compressor:	COPELAND
Temperature in cooling tunnel:	5℃-10℃	Material of machine 1:	Stainless steel and Painted carbon steel	Material of machine 2:	All stainless steel
Name of machine:	chocolate bar machine
