Transformer insulating paper board,China kd price supplier

Transformer insulating paper board

FOB Price:Price can be negotiated

Payment Terms: T/T

Update Time:2024-03-11

Contact Supplier

Product Description

Transformer Presspaper:
It is made from 100% Unbleached sulphate wood-pulp. Cardboard makes which on the intermittent type board machine .Its characteristic is: Material free of strain,very flat , thickness even, the surface smooth, the mechanical strength high, has the obdurability and the electric insulation . Used in oil-cooled power transformers and distribution transformers primarily due to their high purity, mechanical strength and optimal oil-impregnability. The components formed of pressboard, such as angle rings, snout segments and end leads, enable an exact adaptation to the electric field conditions prevailing in the transformer. P ack :sheet size：1000X2000mm、1400X1100mm、1400X2000mm， Color:red ,green,Nature Thickness：0.10，0.13，0.18，0.25，0.38，0.50，0.80,1.00，1.60，2.00，2.50，3.00．4.00mm
PI2(Coil Insulating Paper Class2):Thickness 0.03，0.04，0.05，0.06，0.075，0.08，0.09，0.10，0.13，0.18，0.25，0.38mm
Heat Resistant Papert for Insulating "HPI-Green":Thickness 0.05 , 0.075 , 0.08mm
Special sizes and thicknesses upon request ， process insulation compenents for construction part and Hand-moulded special shape Components as:End Ring ，Clamping Ring ,Bushing,Tubes,Fan-angle,insulating Angle Caps etcs.products through ISO 9001.UL,SGS certification.
Transformer insulating paper board
Application:

	Index.		Unit	Values
				≤1.6	＞1.6～3.0	＞3.0
1	Nominal thickness tolerance		%	≤10（±）
2	Nominal Grammage		g/cm3	1.00～1.20	1.00～1.25	1.15～1.30
3	Shear strength,M.D.		Mpa	≥100	≥105	≥110
4	Shear strength,C.M.D.		Mpa	≥75	≥80	≥85
5	Elongation (M.D.)		%	≥3.0
6	Elongation (C.M.D.)		%	≥4.0
7	Shrinkage		%	≤10.0	≤7.5	≤5.0
8	Shrinkage which would resume		%	≥45	≥50	≥50
11	Shrinkage:	M.D.	%	≤0.5
		C.M.D.		≤0.7
		Thickness direction		≤4.0
12	Moisture content		%	≤6.0
13	Ash content		%	≤1.0
14	Electrical conductivity of aquesous extract		ms/m	≤1.6	＞1.6～3.0	＞3.0
15	Aquesous extract (PH)		—	6～9
16	Oil absorption		%	≥11.0	≥9.0	≥7.0
17	Voltage resistant strength(In air)		MV/m	≥12	≥11	≥10
18	Voltage resistant strength(In oil)		MV/m	≥40	≥35	≥30
