Triple-effect concentrator,China Dapu price supplier

Triple-effect concentrator

FOB Price:Price can be negotiated

Production Capacity:large amount

Payment Terms: FOB or CIF

Update Time:2011-06-18

Contact Supplier

Product Description

The device mainly includes concentration can, condenser, gas liquid separator, cooler and liquid receiving barrel.

The concentration can is of clip sleeve structure, the condensers of row-pipe type, the cooler is of coiled type, the device is suitable for the concentration of the material liquid in such industries as pharmacy, food and chemistry, etc. And as well serves for the recycle of alcohol and simple re-fluency distillation. The contact part of the concentrator and the material is made with the stainless steel, resistant to corrosion and meeting the standard of the GMP.

Technical parameters:

Model	ZN50	ZN100	ZN200	ZN300	ZN500	ZN700	ZN1000	ZN2000
Evaporation(kg/h)	<0.25
Evaporation pressure (Mpa)	20	40	60	80	100	130	160	350
Heating area (M2)	0.4	0.6	0.8	1.1	1.2	2.0	2.5	5.5
Condensation area (M2)	1.2	1.7	2.4	3.0	3.2	3.6	4.5	14
Cooling area (M2)	0.25	0.35	0.45	0.6	0.7	0.85	1.1	3
Receive tank capacity (M2)	15	45	60	76	100	125	140	185
Energy consumption (Kg/h)	23	46	70	92	115	150	185	403
Vacuum (Mpa)	0.08
Equipment weight(Kg)	410	470	605	715	862	1015	1250	2600
Overall dimension (mm)	1200×600×2200	1350×750×2700	1700×800×2700	1800×950×2850	2100×1200×3400	2400×1300×3400	2390×1300×3720	2730×1500×4700
