Tube FiLling and Sealing Machine is suitable for filling all kinds of pasty and viscous fluid and the materials alike, into plastic and composite metal tubes and then internally heating tubes, sealing and printing lot number. It is used in the industries of pharmaceutics, foodstuffs, cosmetic and daily chemicals . With Taiwan's EVIEW touch screen and Taida's PLC control system employed, convenient, visualized and reliable non-touch operation of the machine is effected compact design and auto tube feed. Driving part fully-closed. Tube feeding, marking identification, filling, hot air sealing, code printing, trimming and ejecting out the tube conducted by automatic systerm. Tube feeding is conducted pneumatically, accuratly and reliably. Auto picketage effected by photoelectric inductance. Easy adjustment and dismantling . Intelligent temp.control and cooling system makes operation easy and sealing reliable. With easy and quick adjustment, it is suitable for using multiple kinds of soft tubes for filling. The part contacting materials is made of 316L stainless steel, clean, sanitary and conforming to CMP . With safety device, the machine is shut down when the door is opened. and filling carried out only with tubes fed.
| Filling volume | 5-250ml(tube) |
| Filling accuracy | ≤±1% |
| Capacity | 1800-2400(tubes/h Adjustable) |
| Tube diameter | ??10-50mm |
| Tube length | 210mm (Max. Length) |
| Hopper volume | 40 l |
| Power | 380V/220V(Optional) |
| Air pressure | 0.5-0.7MPa |
| Equipped motor | 1.1 KW |
| Hot air | 3.0KW |
| Dimension (L×W×H): | 1900×1000×1950mm |
| Weight: (Approx) | 850kgs |
Founded in 1989, Wenzhou Rigao Packing Machinery Co., Ltd. is one of members of China Packing Technology Association, China Association of Surfactant Soap and Detergent Industries, China Association of Fragrance Flavor and Cosmetic Industry, Zhejiang High Technology Enterprise, and Zhejiang High-tech Small and Medium-Sized Enterprises, integrating R&D, manufacture, distribution and service in automatic packaging machinery industry. We have Obtained ISO9001: 2000 quality management system authentication and our Tube filling & sealing machine and series filling machines have passed CE authentication.
With nearly two decades of development, we have been congregating many talents in machine manufacturing industry and keep ahead in researching and developing. We offer packing solutions for our customers throughout the pharmaceutical, cosmetic, foodstuff, and lubricant and some other industries . More than 80% of our products are exported to countries all over the world, enjoying favorable remarks.
Based on the company's tenet of "Innovation, Honesty, Harmony, efficiency and sustainability", Rigao Company provides reliable products and satisfying service to customers and share the brilliant future!
|
|
|
|
|
|
|
|
|
|
|
|
