Turn-key basis 20TPD edible soybean oil refining line

Technical and Economic Indicators :

Refining loss per ton :

De-gumming and de-Acid loss :

The yield of oil depen ds on value of W, calculating by the following formula :

When W ≤3%,Loss =0.3+(1.25 x W)

When W >3%,Loss=1.35 x W

When encountered a second time, the loss will increase around 0.3%. W equals to the sum of MIU(moisture, mechanical impurity, in-saponified matter), FFA, non-oil matter.

Loss in bleaching section : oil residue in used bentonite is less than 20% ;

Loss in de-waxing: oil residue in Filter cake is 30-40%.

Loss on deodorizing(Physical refining process) :

   0.2-3%                               1.25

     3-5%                                 1.20

5-10%                               1.18

Refining loss equals to the amount of FFA in crude oil multiplied the following factor :

FFA in the crude oil                     loss factor

   0.2-3%                               1.25

     3-5%                                 1.20

5-10%                              1.18

Utility consumption (per ton) :

Water :

Recycling water : 140 ~ 150 T/h

Supplying new water : 0.25 ~ 0.3T/T oil

Power : 82.5 Kw.h/T oil

Steam :( pressure 6kgf/cm ² ) 490 ~ 520kg /T oil

Coal consumed by thermo oil furnace : 15 ~ 17Kg /T oil

Phosphorus acid ( 80% concentration ): 1 ~ 2Kg /T oil

Bentonite : 8 ~ 20kg /T oil

filter aid: 5 ~ 10 kg /T oil

Citric acid : 0.5 ~ 1Kg /T oil

Remarks : The cost of NaOH depends on FFA content in crude oil and refining method.
