UHT tubular Pasteurizer,China Kaae price supplier

UHT tubular Pasteurizer

FOB Price:Price can be negotiated

Production Capacity:200 Set/Sets per Year

Payment Terms: US $1,000 - 500,000 / Set

Update Time:2021-04-27

Contact Supplier

Product Description

1 Liquid pasteurizer
2 High heat rate
3 Automation
4 Good Quality, SS304
5 Good price, service.

Tubular UHT sterilizer advantage

1 High heat efficiency, 90% of heat reused.

2 Automation control

3 Sterilize thoroughly and fully

4 with self CIP and SIP system

Usage

1 Mainly used for aseptic filling packing types products, such as tetra paper brick, tetra paper pillow, aseptic soft plastic bag, aseptic PET bottles,especially used for liquid Milk and juice.

2 It can be used to do continuous sterilizing and be connected to homogenizer and water removing equipment.

Technical Data

Model	KATG-UHT-1.5	KATG-UHT-3	KATG-UHT-5
Capacity(L/H)	1500	3000	5000
Inlet temperature	25-40 °C	25-40 °C	25-40 °C
Holding temperature time(s)	120-180	120-180	120-180
Sterilizing temperature	95-121 °C	95-121 °C	95-121 °C
Outlet temperature	25-35 °C	25-35 °C	25-35 °C
Tower water inlet temperature (°C)	-30	-30	-30
Steam pressure	0.5Mpa	0.5Mpa	0.5Mpa
Steam consumption	-150Kg/h	-210Kg/h	-280Kg/h
Compressed air pressure	0.6Mpa	0.6Mpa	0.6Mpa
Compressed air consumption	50L/H	50L/H	60L/H
Overall dimensions(LWH)	700020002000	700020002000	700020002000
Weight	1700Kg	2000Kg	2200Kg

Place of Origin:	Jiangsu China (Mainland)	Brand Name:	Kaae	Model Number:	Ka
Usage:	Sterilizer	Type:	Sterilizer	Material:	stainless steel
Industrial used:	Dairy, beverage etc	Sterilized type:	High temperature	Certification:	ISO, CE certification
