Flake ice:
The irregular ice flake with thickness around 1.5-2.5mm.
Air cooled industrial Flake Ice Machine (0.5T-30T/24H)
Feature:
1.The ice flake produced by the ice makeing machine can be directly used for stirring
and mixing refrigerated material.
2.There's no acute edges and sharp points on the ice flake,so it will not damage the
surface of the cooled object.
3.Large contact area and fast cooling speed,easy to crush and mold.
Application fields:
Concrete cooling system for concrete mixing plants, Lab Refrigeration for chemical plants, Mine cooling,
skiing and skating ground, Medical cryogenic equipment for Medicine, aquatic food and so on
| Flake ice evaporator technical parameter | |||||||||
| Model | Ice output (kg/24h) |
Cooling capacity(KW) | Power | Total Power (KW) |
Regrigerants | Cooling Way | Single Barrel Dimension(mm) | Net Weight (kg) |
Capacity of Freezer |
| LR-05T | 500 | 3.7 | 3P/38OV/50Hz | 2.5 | R404A | Air-cooled | 1310*890*780 | 195 | 400 |
| LR-1T | 1000 | 6.5 | 3P/38OV/50Hz | 4.8 | R404A | Air-cooled | 1310*970*880 | 227 | 500 |
| LR-1.2T | 1200 | 7.8 | 3P/38OV/50Hz | 5.47 | R404A | Air-cooled | 1310*970*980 | 263 | 500 |
| LR-1.5T | 1500 | 9.8 | 3P/38OV/50Hz | 7.3 | R404A | Air-cooled | 1310*970*980 | 364 | 500 |
| LR-2T | 2000 | 13 | 3P/38OV/50Hz | 8.5 | R404A | Air-cooled | 1500*1095*1040 | 423 | 600 |
| LR-2.5T | 2500 | 16.2 | 3P/38OV/50Hz | 9.2 | R404A | Air-cooled | 1500*1095*1200 | 456 | 600 |
| LR-3T | 3000 | 19.5 | 3P/38OV/50Hz | 12.2 | R404A | Air-cooled | 1750*1190*1200 | 530 | Actual demand of cumtomer |
| LR-4T | 4000 | 26 | 3P/38OV/50Hz | 16.3 | R404A | Water-cooling | 1700*1650*1450 | 630 | |
| LR-5T | 5000 | 32.5 | 3P/38OV/50Hz | 19.6 | R404A | Water-cooling | 1700*1650*1450 | 760 | |
| LR-8T | 8000 | 49 | 3P/38OV/50Hz | 26.6 | R22 | Water-cooling | 2500*2000*1560 | 968 | |
| LR-10T | 10000 | 65 | 3P/38OV/50Hz | 32.5 | R22 | Water-cooling | 2500*2000*1700 | 1260 | |
| LR-15T | 15000 | 95 | 3P/38OV/50Hz | 58 | R22 | Water-cooling | 3100*2160*1865 | 2120 | |
| LR-20T | 20000 | 130 | 3P/38OV/50Hz | 63 | R22 | Water-cooling | 3100*2160*2050 | 2860 | |
| LR-25T | 25000 | 160 | 3P/38OV/50Hz | 75 | R22 | Water-cooling | 3100*2160*2265 | 2940 | |
| LR-30T | 30000 | 195 | 3P/38OV/50Hz | 86 | R22 | Water-cooling | 3500*2700*2350 | 3240 | |
Shenzhen Lier Machinery Equipment Co.,Ltd has been adhering to "the business principle of quality&customer oriented" and "innovative concept of professional design, technology leadership of future". Lier has been committing to researching, producing, and project installation and after-sales service.
Located in Songgang Town ,Shenzhen, close to Shenzhen International Airport and Guangzhou-Shenzhen High-speed exit, Lier can enjoy convenient transportation and has nearly ten thousand square meters plant. With the advantages of advanced equipment &production technology, modern management system, strict quality control, senior technical personnel and high qualified staff, Lier and it's products are servicing people widely.
Lier ice-making machine has various types and is widely used ,including small commercial ice-making machine with daily output of 0.5ton to set of ice-storage&making delivery system.. Our products are widely applied in processing&preservation of aquatic products and fruit&vegetable, poultry slaughter, meat processing, machine&chemical projects, textile printing, deep-sea fishing, laboratory refrigeration and concrete pouring,etc. Meanwhile, we'll supply customers with the most rational&efficient design and the best ice program to meet customer's demand.
Our eternal goal is "to maintain technology and innovation" and "to keep beyond quality and service".We'll cooperate with all customers with our professional. Honest and win-win spirit.
|
|
|
|
|
|
|
|
|
|
|
|
|
