Scope of application:
This machine was designed for small granular materials, such as detergent ,washing
powder,sugar, salt,beans, rice, legume, coffee, grain, seeds, nuts, condiments,
peanuts,etc.
Function and features:
1. This machine can finish these work automatically: measuring--making bag--coding (option)--filling--gas injection(option)--sealing--counting.
2. PLC control system, photoelectric tracking system, which improve the control precision, reliability and intelligence at the maximum limit.
3. Has fault display system, easy to operate and maintain.
4. Make punching blade after customer's special request.
5. Machine body and all parts touching product: made by 304 stainless steel .
Technical parameter:
Production capacity
|
20-60 bags/min
|
Packing weight
|
10g-1000g
|
Forming bag size
|
L 50-300mm, W 50-200mm
|
Accuracy
|
≤±1%
|
Power supply
|
1 Ph 220V, 50/60Hz, 1.9kw
|
Machine weight
|
350kg
|
Machine dimension
|
800*1100*1900mm
|
Spec of wooden box
|
450kg, 1250*1100*2100mm
|
Sealing type
|
Pillow seal
|
Skyp e: amychanningcn
Shanghai BangYang packing machine company is especial food packing machine manufacture in Shanghai,China.
The main products is mainly of automatic Vertical from fill seal packing machine, automatic flow packing machinen, multifunction vertical packing machine, and filling machine .
Those products has been export to more than 30 countries.
