stable in operation and convenient in maintenance
high efficiency,large capacity
fully enclosed structure, widely used
Vibration Fluid Bed Dryer for desiccated coconut
The drier is suitablity in chemical industry,light industry, pharmaceutical, food, plastic, oil, slang, salt, sugarand so on, for drying, cooling and weting.
The vibration is created by motorl is stable in operation and convenient in maintenance, low noise and long life.
1.High effection,raw material is heates evenly and heated evenly and heat exdhange is fully used and dry capacity is high. Compared with ordinary drier, the energy can be saved about 30%.
2.It is good in regulation and wide in suitablity. Tje thickness of raw material layer and movable speed inside the maching and the amolitude can be adjusted through continous variable speed.
3. It is small for danaging the are surface of raw material. Theequipment can be used for drying raw materials that are easy broken. The drying effect can not affected even if raw materials have anomaly shape.
4. A fully enclosed structure, effectively prevent the material and the air space between the cross infection of the working environment clean.
5. You can string multi-srt to raseed capacity of raw materials, such as polyacrylamide.
Model | Fluidized bed area m2 | Temperature of air in °C | Temperature of air out °C | Capacity of vaporize moisture Kg/h | Vibration motor | |
Model | Power(Kw) | |||||
ZLG3×0.30 | 0.9 | 70~140 | 40~70 | 20~35 | YZS8-6 | 0.75×2 |
ZLG4.5×0.30 | 1.35 | 35~50 | YZS10-6 | 0.75×2 | ||
ZLG4.5×0.45 | 2.025 | 50~70 | YZS15-6 | 1.1×2 | ||
ZLG4.5×0.60 | 2.7 | 70~90 | YZS15-6 | 1.1×2 | ||
ZLG6×0.45 | 2.7 | 80~100 | YZS15-6 | 1.1×2 | ||
ZLG6×0.60 | 3.6 | 100~130 | YZS20-6 | 1.5×2 | ||
ZLG6×0.75 | 4.5 | 120~170 | YZS20-6 | 2.5×2 | ||
ZLG6×0.9 | 5.4 | 140~170 | YZS30-6 | 2.2×2 | ||
ZLG7.5×6.0 | 4.5 | 130~150 | YZS30-6 | 2.2×2 | ||
ZLG7.5×0.75 | 5.625 | 150~180 | YZS40-6 | 3.0×2 | ||
ZLG7.5×0.9 | 6.75 | 160~210 | YZS40-6 | 3.0×2 | ||
ZLG7.5×1.2 | 9 | 200~280 | YZS50-6 | 3.7×2 | ||
ZLG7.5×1.5 | 11.25 | 230~330 | YZS50-6 | 3.7×2 | ||
ZLG8×1.8 | 14.4 | 290~420 | YZS75-6 | 5.5×2 |
Changzhou Yiqiu Zhongya Drying Equipment Factory is located at Jiaoxi Town, East Suburb of Changzhou, a key enterprise of drying industry in China and also specially-designated productive unit of National pharmaceutical machinery, chemical equipment, foodstuff machinery. For many years the factory persists in the principle,i.e. with science and technology as forerunner and with market as guide and with raising the productive benefit of customers as tenet. Meanwhile the factory has united with several universities and colleges and institutes and carried out technical cooperation in the fields of drying equipment, pharmaceutical machinery, chemical equipment, foodstuff machinery and so on. The situation of powerful-powerful combination has been formed.
Certifications
If any interests, please contact with me as follows:
MS Jane Dai
Foreign Trade Dept saleswoman
Tel:0519-88905858
Fax:0519-88902513
URL: www.yiqiu.com
Condition: |
New
|
Type: |
Fluid Bed Drying Equipment
|
Place of Origin: |
Jiangsu China (Mainland)
|
Brand Name: |
YIQIU ZHONGYA
|
Model Number: |
ZLG
|
Voltage: |
220-440v
|
Power(W): |
1-11kw
|
Dimension(L*W*H): |
based on actual design
|
Weight: |
1240-8600kg
|
Certification: |
ISO9001:2000
|
Warranty: |
one year
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
Material: |
SUS304/316/Carbon steel
|
Control system: |
Touch screen
|
Heating source: |
Hot air furnace or steam
|
