1.Extensive use
2.No block mesh
3.Can be designed as client's request
4.High screening efficiency
Vibration sieve for Corn Starch
Ø We are the leading manufacturer specialized in designing and manufacturing rotary vibrating screen in china with the experience of more than 20 years.
Ø Manufacturing according to the ISO9001:2008 quality control system guidelines.
Ø Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs.
Ø Workers are locals in china, low production cost.
1. Function : screening and filtering any powder or particle material
2. Diameter : 400mm, 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm
3. Sieve layer : 1-5 layers, the 1-3 layers is better
4. Screen size range : 10mm-500 mesh.
5. Driven mode : vibration motor driven.
6. Material : carbon steel, material contact parts are stainless steel or all are of stainless steel.
Features
1.Function: Screening and filtering any powder or particle material
2.Diameter: 400mm, 600mm, 800mm, 1000mm, 1200mm, 1500m, 2000mm
3.Movement Locus: Upwards , Left and Right Motion, Rotation Motion.
4.Sieve Layer: 1-5 Layers, the 1-3 layers is better.
5.Screen Size Range: 10mm-500 mesh.
6.Driven Mode : Vibration Motor Driven.
7.Material : Carbon Steel, Material Contact Parts are Stainless Steel or All are of Stainless Steel
Models for you to choose
| Model | Power | Sieve diameter | Dimensions (mm) |
Layer |
| M400-1s | 0.25kw | 350mm | 580*580*560 | 1 |
| 2s | 580*580*670 | 2 | ||
| 3s | 580*580*780 | 3 | ||
| M600-1s | 0.55kw | 550mm | 800*800*750 | 1 |
| 2s | 800*800*890 | 2 | ||
| 3s | 800*800*1030 | 3 | ||
| M800-1s | 0.75kw | 750mm | 900*900*750 | 1 |
| 2s | 900*900*890 | 2 | ||
| 3s | 900*900*1030 | 3 | ||
| M1000-1s | 1.47kw | 950mm | 1160*1160*810 | 1 |
| 2s | 1160*1160*950 | 2 | ||
| 3s | 1160*1160*1090 | 3 | ||
| M1200-1s | 1.84kw | 1150mm | 1360*1360*885 | 1 |
| 2s | 1360*1360*1050 | 2 | ||
| 3s | 1360*13601275 | 3 | ||
| M1500-1s | 2.2kw | 1430mm | 1850*1850*990 | 1 |
| 2s | 1850*1850*1185 | 2 | ||
| 3s | 1850*1850*1380 | 3 | ||
| M1800-1s | 3.0kw | 1700mm | 2200*2200*1050 | 1 |
| 2s | 2200*2200*1250 | 2 | ||
| 3s | 2200*2200*1450 | 3 |
1. Vibrating Separator installation,Debugging.
Provide sand vibrating sieve machineinstallation files, technical data and related soft
copies or videos etc
2. Vibrating Separator warranty
The provider guarantee the carbon black vibration screen could meet production technical standard and performance requirements indicated in the contract.
Warranty: 24 months for the machine after delivery,12 months for the motor after delivery.
3. Vibrating Separator technical support
Our company will make occasional call to find problems and solve them in time.
Provide technical support timely.
4. 24 hours website hot line service.
For big Circular vibrating screen order,to dispatch technician is negotiable. Aftersales Guarantee.
Note:
How could you choose suitable one? Please answer the following questions.
Capacity:_____t/h
Screen deck: _____
Mesh size:_____mm
Processing material:_____
| Condition: |
New
|
Type: |
Circular
|
Application: |
Food Processing
|
| Place of Origin: |
Henan China (Mainland)
|
Brand Name: |
Remont
|
Model Number: |
M400
|
| Voltage: |
380V/460V
|
Power(W): |
50HZ
|
Dimension(L*W*H): |
580X580X560
|
| Weight: |
55kg
|
Certification: |
ISO
|
Warranty: |
1 year
|
| After-sales Service Provided: |
Engineers available to service machinery overseas
|
Category: |
Vibration sieve for corn starch
|
Material: |
carbon steel or stainless steel
|
| Function: |
screening and filtering
|
Layer: |
1-5
|
Power: |
0.25-3kw
|
| Valid arer: |
0.0962-2.4593
|
Shape: |
round
|
Diameter: |
350~1700mm
|
| Model: |
M400-M2000
|
Size of mesh: |
5-500mesh
|
