Water washing-filling-capping machine is designed especially for non-carbonated drinks such as Mineral Water,pure water,wine.
Water washing-filling-capping machine is designed especially for rinsing , filling , capping non-carbonated drinks such as mineral water , pure water , wine .
The max. producing capacity of the machine is 36000 B/H .With the special designed filling valves, the machine can control the filling liquid level precisely ;According to the requirement of refluence for the liquid , we use the Sanitary recycle system in the machine .And the entire CIP refluence system in the machine will ensure the rinsing effect.
For the PLC system in the machine, we will use the international famous brand such as Omron , Keyence ,Mitsubishi.And also we will adopt the English MMI for the machine .
| Model |
RFC |
RFC |
RFC |
RFC |
RFC |
|
| 8-8-3 |
18-18-6 |
24-24-8 |
60-60-20 |
80-80-24 |
||
| Producing Capacity(500ml/B/H) |
2000-3000 |
5000-6000 |
8000-10000 |
18000-20000 |
32000-34000 |
|
| Rinser Header |
8 |
18 |
24 |
60 |
80 |
|
| Filler Valves |
8 |
18 |
24 |
60 |
80 |
|
| Capper Header |
3 |
6 |
8 |
20 |
24 |
|
| Bottle Type |
Round PET bottle or Square PET bottle |
|||||
| Bottle Diameter |
φ50mm-φ90mm |
|||||
| Bottle Height |
150mm-310mm |
|||||
| Filling Precision |
±5mm |
|||||
| Compresses Air Pressure |
0.3 Mpa -0.7 Mpa |
|||||
| Rinsing Medium |
sterile water |
|||||
| Rinsing Water Pressure |
0.25 Mpa |
|||||
| Total Power |
2.5 |
3.75 |
5.6 |
11 |
15 |
|
| Dimension(mm) |
1900×1400×2300 |
2400×1900×2300 |
3010×2180×2400 |
6500×3500×2400 |
6800×3900×2400 |
|
| Weight |
2500 kg |
3500 kg |
4200 kg |
13000 kg |
15000 kg |
|
| Product Type: Beverage | Place of Origin: Jiangsu China (Mainland) | Brand Name: YaXing |
