Be suitable for automatic labeling round bottles with different diameter and height in pharmaceutical, daily chemical an so on.
·
Be suitable for automatic labeling round bottles in pharmaceutical, daily chemical, food and beverage industries.
·
Can be used for labeling square bottles by changing some parts.
·
Be suitable for labeling bottles with different diameter and height with this machine.
·
Be able to supply customized solutions to meet different labeling needs.
Features:
·
Touch screen: Highly user friendly, provides detailed on-line help and error warning.
·
Labeling parameters storage: Up to 50 labeling parameters can be stored in the machine (including bottle diameter and label length and so on). Do not need to reset the parameters which changing bottles.
·
Bottle separating roller: It is applicable to all bottles and easy for adjustment.
·
Bottles feeding and collecting device:Can be used either stand-alone (with feeding and collecting device), or integrated easily into the existing production line.
·
Coding system: Optional thermal transfer, hot-stamp coder or inkjet coder for synchronized coding on the labels.
·
Optional machine vision detection system: Provides automatic detecting of the printed data and labels to eliminate the errors such as missing labels, shifted position, and double labels etc.
·
Intelligent label control: Provides low label warning.
·
Imported servomotor control: Unique sand-glass material label traction roller, which is characterized with excellent driving grip and wear resistance. The traction roll will ensure durability and dispensing accuracy over the long term.
·
All electrical components are of world renowned brands, ensuring long term stability and reliability of the machine.
Technical Specification:
·
Model: SL-101
·
Diameter of bottles: 20-90mm, 30-160mm
·
Speed: 100-250 cards/Min
·
Labeling Accuracy: ±1.0mm
·
Power Supply: 220VAC, Hz
·
Power: 500w
