Product profile

YC-015 Lab Spray dryer(mini spray dryer) have been applied by over 2,500 domestic customers of first class universities, enterprises and research institutes including AMSS Institute of Systems Science, Tsinghua University, Shanghai Jiao Tong University, South China University of Technology, Wuhan University, Tongrentang, Xiehe Pharmaceutical, Bright Dairy, Hong Kong Polytechnic University, Harbin Pharmaceutical Group, Strong Group, General Electric (GE) Shanghai R&D Center, Jiangnan University, China Agricultural University, Zhejiang University, Tongji University and Huazhong University of Science and Technology，and exported to over 30 countries and regions such as the United States, Italy, South Korea, Singapore, Canada, Malaysia, Chile ,Russia and so on, respecting reputation in view of good product quality.

YC-015 lab spray dryer (mini spray dryer)is self contained and supplied complete and ready for immediate operation. All major components are housed within a stainless steel cabinet and the unit can be used on a bench top or with an optional stainless steel stand. The system was designed to be stand by a keyboard, conducted by a colorful crystal screen of touch guidance mode , and allowed two modes of run: Automatic-mode, and Eye-monitored mode for the purpose of easily controlling experimental process .

Technical Parameter

1.Automatic-mode and Eye-monitored mode for the purpose of easily controlling experimental process ,English interface.

2.Evaporation rate of water at inlet temperature of 250ºC using Standard:Approximately 1500 ml/hour

3.Air inlet temperature range 30ºC to250ºC

4.Air outlet temperature range 30ºC to 140ºC

5.Max. Sample feed: 1500ml/h

6.Min. Sample : 30mL

7.To assure accurate temperature control and easy parameter adjusting, YC-015 applies PID. Temp. Precision:±1℃, dry cycle time: 1.0-1.5S

8.As standard a touch screen to display temperature, airflow volume, air pressure,pump speed and de-blocker frequency.

9.standard with 0.7 mm jet and other sizes are available as accessories(0.5mm 1mm 1.5mm 2mm)

10.Spray chamber, cyclone separator, receiving tank are all made of Borosilicate glass which can resist strong acid/alk li, high temperature. It can work in a no-pollution and stable environment, and the whole process can be inspected. All the spare parts are easy to install and wash.

11.Power: 3.5KW AC220V

12.With cooling device for temperature-sensitive material  (optional)
