Zhangjiagang sparkling water filling machine,China winmark price supplier

Zhangjiagang sparkling water filling machine

FOB Price:Price can be negotiated

Production Capacity:500 Set/Sets per Year sparkling water

Payment Terms: US $15,000 - 50,000 / Set

Update Time:2014-09-16

Contact Supplier

Product Description

1.sparkling water Filling Machine
2.3-in-1 washing filling &capping
3.PLC control , full automatic
4.CGFtype , 12000bph

sparkling water filling machine

Automatic sparkling water filling machine Beverage filling Machinery: This CGF Wash-filling-capping 3-in-1unit:Beverage Machinery is used to produce polyester bottled Mineral Water, purified water, alcoholic beverage machinery and other non-gas beverage machinery. The CGF Wash-filling-capping 3-in-1unit:Beverage Machinery can finish all the process such as press bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency. Beverage Machinery-Equipment characteristics: 1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier. 2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough.. 3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution. 4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose. 5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains. 6. Host adopts advanced PLC automatic control technology, the key electrical components from famous company such as Japan\'s Mitsubishi, France Schneider, OMRON.

Model:	YF12/12/4	YF16/12/6	YF18/18/6	YF24/24/8	YF32/32/10
Heads of washing filling sealing	12-12-4	16-12-6	18-18-6	24-24-8	32-32-10
Production Capacity:500ml(B/h)	3000	4000	6000	10000	12000
Suitable Bottle Standard:(mm)	φ=50-100mm, H=150-300mm, 330-1500ml	φ=50-100mm, H=150-340mm, 330-1500ml	φ=50-100mm, H=150-340mm, 330-1500ml	φ=50-100mm, H=150-340mm, 330-1500ml	φ=50-100mm, H=150-340mm, 330-1500ml
Suitable cap type	plastic screw	plastic screw	plastic screw	plastic screw	plastic screw
Filling Pressure:(Mpa)	0.2-0.25	0.2-0.25	0.2-0.25	0.2-0.25	0.2-0.25
Motor power	2.2	2.2	3.0	3.0	4.0
Filling Temperature:	Room temperature	Room temperature	Room temperature	Room temperature	Room temperature
Overall dimension(L×W×H(mm)	2450×1450×2300	2400×1670×2350	2470×1970×2350	2865×2170×2350	4000×2570×2500
Total weight: (kg)	2500	2500	3000	4000	5000

mineral water production equipment

mineral water production equipment mineral water production equipment mineral water production equipment mineral water production equipment mineral water production equipment mineral water production equipment mineral water production equipment mineral water production equipment mineral water production equipment mineral water production equipment

Type:	Filling Machine	Condition:	New	Application:	Food,Beverage
Packaging Type:	Bottles	Packaging Material:	Plastic	Automatic Grade:	Automatic
Driven Type:	Electric	Voltage:	depending on client	Power:	subject to model
Place of Origin:	Jiangsu China (Mainland)	Brand Name:	winmark	Model Number:	CGF32-32-10
Dimension(LWH):	240017602350mm	Weight:	2500KGS	Certification:	CE ISO
After-sales Service Provided:	Engineers available to service machinery overseas	Factory location:	2 Hours from shanghai	material:	SUS304
Control:	PLC SIEMENS Mittisubishi	Touch screen:	WeinView Taiwan	Electronics:	Schneider OMRON
Pneumatic:	FESTO Air-Tac	Motor:	NanFang	capacity:	Adjustable fully automatic
function:	Bottling machines
