Zhengzhou Yufeng high efficient rotary dryer for drying coconut, sand, bagasse,China Yufeng Brand price supplier

Zhengzhou Yufeng high efficient rotary dryer for drying coconut, sand, bagasse

FOB Price:Price can be negotiated

Production Capacity:10 Set/Sets per Month

Payment Terms: US $9,999 - 200,000 / Set

Update Time:2023-10-08

Contact Supplier

Product Description

Rotary Dryer:
1.low noise, little poll
2.designed with anti-sticky drum-wall

Zhengzhou Yufeng high efficient rotary dryer for drying coconut, sand, bagasse

Introduction:

Rotary dryer is handling by bringing it into direct contact with a heated gas. The dryer is made up of a large, rotating cylindrical tube,The dryer slopes slightly so that the discharge end is lower than the material feed end in order to convey the material through the dryer under .

Working principle of the rotary dryer

Material to be dried enters the dryer, and as the dryer rotates, the material is lifted up by a series of internal fins lining the inner wall of the dryer. When the material gets high enough to roll back off the fins, it falls back down to the bottom of the dryer, passing through the hot gas stream as it falls. This gas stream can either be moving toward the discharge end from the feed end (known as co-current flow), or toward the feed end from the discharge end (known as counter-current flow). The gas stream can be made up of a mixture of air and combustion gases from a burner, in which case the dryer is called a direct heated dryer. Alternatively, the gas stream may consist of air or another (sometimes inert) gas that is preheated. When the gas stream is preheated by some means where burner combustion gases do not enter the dryer, the dryer known as an indirect-heated type. Often, indirect heated dryers are used when product contamination is a concern.

Specifications of Drier

Specific-ations(m)	Capacity(t/h)	Main motor		Main gear box		Weight(t)
Specific-ations(m)	Capacity(t/h)	Power(kw)	Model	Model	Speed reduction ratio	Weight(t)
ø1.2*10	2.5	7.5	Y160M-R3	ZL50-16-I	-----	13.5
ø1.5*12	3.3-4.9	10	Y160L-6-B3	JZQ500-III-2F	-----	18.9
ø1.5*15	4-6	18.5	Y200L1-6	JZQ500-III-2F	-----	21
ø1.8*12	4-6	18.5	Y160L-6	ZQ50-16II-2	16.46	22.83
ø2.2*12	7-12	18.5	Y200L7-6	JZQ650-III	31.5	37.6
ø2.2*14	7-12	22	Y200L7-6	JZQ650-III	31.5	40
ø2.2*16	12	30	Y225M-6	JZQ750-III	31.5	45
ø2.4*14	12	30	Y250M-6	JZQ750-III	31.5	51
ø2.4*18	10-13	37	Y250M-6	ZL85-13-I	27.16	54
ø2.4*20	10-14	37	Y250N-6	ZL85-13-I	27.16	54.14
ø3*20	25	55	Y250M-4	ZL100-16-I	41.52	78
ø3*25	32-36	75	YR280M-4	ZL100-16-I	41.52	104.9

If you have any other questions about our products, you can contact Marcie Liu through the skype: driermachine, or the mobile cell:+0086 18236781826.

Condition:	New	Type:	Rotary Drying Equipment	Place of Origin:	Henan China (Mainland)
Brand Name:	Yufeng Brand	Model Number:	rotary dryer	Voltage:	380v
Power(W):	75kw	Dimension(LWH):	as the different models	Weight:	as the different model
Certification:	CE, ISO,ISO9001:2000	Warranty:	2 years	After-sales Service Provided:	Engineers available to service machinery overseas
color:	as per buyer requirement	Application:	Drying Water From 40 to 5%	Capacity:	40 t/h
Installation:	by our engineers

Company Profile

Name: Zhengzhou Yufeng Heavy Machinery Co., Ltd.

Main Products: Mining Machine,AAC Plant,Cement Plant,Dryer

Business Type: Manufacturer, Trading Company

Total Employees: 101 - 200 People

Established Year: 2010

Main Markets: South Asia, South America, Africa, Domestic Market, North America

Address: High & New Tech Industry Area, Zhengzhou City, Henan, China

Zhengzhou Yufeng Heavy Machinery Co., Ltd is one of biggest Autoclave Aerated Concrete (AAC) equipments and other mining machinery manufacturer and supplier in China.
The company mainly deals with AAC block equipments, Mining crushing and screening equipments, Mineral processing equipments, Wet material drying equipments, Mine powder production classifying equipments and lime and cement production equipments and other equipments, products widely used in mineral processing, metallurgy, building materials, chemicals, electricity, petroleum, coal, transportation, fertilizer gas industry etc.

In recent years the company has increased market share and profits significantly as well as becoming one of the leading companies in the industry in China. In 2005 Yufeng was rated one of the best 100 enterprises of Henan Province and one of the best 500 enterprises of China construction machinery manufacturers. And company was awarded "Provincial management model enterprise" "Quality Management Advanced units of Henan Province "State-level high-tech enterprises" "100 Honesty Enterprises in Henan Province". According to the development strategy of "To build Yufeng a famous brand" our group is on our way to be a domestic first-class, world-renowned engineering machinery manufacturing enterprises.

Production Capacity
1. Annual 20,000m3-300,000 m3 Fly ash type and Sand type AAC block plant
2. 10-200ton per hour Mineral processing equipments
3. Kinds of drying and roasting equipments and milling equipments
4. 10-500ton per hour artificial stone and sand crushing and screening equipments

Export Destinations: Korea, Australia, India, Pakistan, Sri Lanka, Philippine, Malaysia, Nepal, Russia, Bolivia, Brazil, South Africa and so on.
AAC Plant Manufacturing Capacity: average 40 complete sets of production line with different capacity annually.

We orient the international standard to plan from quality management, technique, inspection to production, and strictly do in each aspect, offering the first techniques and service. more
