Features
1. Auto measuring, making bags, filling, sealing, cutting and printing embossing dates.
2. Easy to operate and smart to move.
3. Finished bag can be cutted seperately or just like a chain.
Application
Widely used in food, cosmetics, chemical and medicine industry. Suitable for packing liquid or paste products such as jelly, juice, sauce, ketchup, honey, jam, oil, etc.
| Rows | 4/6/8/10-lanes |
| Article | Liquid |
| Model | DXD-480Y/680Y/880Y/1080Y |
| Measuring Range | 1-50ml/bag |
| Max film width | 480mm/680mm/880mm/1080mm |
| Size of bag | L55-220mm W40-80mm |
| Capacity | 120-400bag/min |
| Control style | PLC control system + Chinese/English interface |
| Case of machine | Spray painting / Stainless steel |
| Material feeder | pneumatic / mechanical |
| Air consumption | 0.24m³/min 0.6Mpa |
| Power | 1200W |
| Power supply | AC380V 50Hz / AC 220V 50Hz |
| Weight | N.W310kg G .W355kg |
| Dimensions (mm) | 1300*1100*1600 |
| Material of bag | Paper/polyethylene cellophane/polyethylene plated aluminum/polyethylene BOPP/polyethylene nylon/polyethylene |
| Sealing style | 4 sides sealing |
| Function | Packaging 4 or 8 bags in one time. Measure volume, making bags, filling, sealing, printing datecode, cutting easy tearing notch. I can be used to pack the fluidity of foodstuff, chemicals, cosmetics etc. Such as shampoo, facial cream, flavor oil, fruit juice, ketchup, sauce, Butter and so on. |
Guangzhou Yilugao Packing Machinery Technic manufactures, sells, and services vertical form, fill, and seal packaging machines (VFFS) for the packaging industry. Our global markets include food and beverage, pharmaceutical and nutraceutical, and hardware, among others.
